Lawn Tractor · 1963Unverified

John Deere 110

Name: John Deere 110
Brand: John Deere

John Deere 110 — Model year 1963-19671968-1974 · 7 hp. Reference specifications; pending source verification.

The John Deere 110 is a lawn tractor with a rating of approximately 7 hp, positioning it at the lighter end of its class. It was produced from 1963 to 1974. The model features a 1-cylinder petrol air-cooled engine and two-wheel drive, paired with a continuously variable transmission. Its operating weight is listed as 227 kg and it is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

7 hp

Weight

227 kg

Catalogue coverage

Variants represented

Richest spec table

102 rows

Recorded power

7 hp

Recorded weight

227 kg

Transmissions

3-speed gear with mechanical CVT

Production years

1963-1974

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Garden tractorReference

Built in Horicon, Wisconsin, USAReference

The "10" in the John Deere 110 model name did not refer to the tractor's horsepower, but was keeping in line with the New Generation tractor models (1010, 2010, 3010, 4010).Reference

Two-wheel driveReference

Manual steeringReference

Manual brakesReference

Open operator station.Reference

Variants

110Hhydraulic liftReference

Engine

7HP Kohler 277cc 1-cyl gasolineReference

8HP Kohler 305cc 1-cyl gasolineReference

Fuel tank7.2 LReference

Kohler K161Reference

gasolineReference

1-cylinderReference

air-cooled horizontal-shaftReference

The Kohler K161 was the original engine on the John Deere 110. It was used only during the 1963 model year.Reference

Displacement16.94 ciReference

Bore/Stroke73 x 64 mmReference

Power5.2 kWReference

Rated RPM3600Reference

Idle RPM1200-3800Reference

Starter volts12Reference

Sparkplug gap0.635 mmReference

Point gap0.508 mmReference

Oil capacity1.1 LReference

Oil change25 hReference

Kohler K181SReference

The 8-horsepower Kohler K181 replaced the K161 for the 1964 model year.Reference

Displacement18.64 ciReference

Bore/Stroke75 x 70 mmReference

Power6.0 kWReference

Air cleanerdryReference

Compression6.8:1Reference

Intake valve clearance0.178 mmReference

Exhaust valve clearance0.406 mmReference

Oil capacity0.9 LReference

Transmission

3-speed gear with mechanical CVTReference

4-speed gear with mechanical CVTReference

ManufacturerPeerlessReference

Typebelt-driven gear with mechanical CVTReference

Gears3 forward and 1 reverseReference

Oil capacity0.9 LReference

Oil change200 hReference

1Clutch-Brake pedalReference

2ThrottleReference

3Variator leverReference

4Gear shiftReference

5Parking brakeReference

TransmissionPeerless 2300Reference

Gears4 forward and 1 reverseReference

Oil capacity1.4 LReference

The transmission features four forward gears plus reverse, with a variable speed control. The clutch is used to shift between gears. Once in gear, the variable speed lever adjusts the drive ratio to provide a range of speeds that can be adjusted on the move.Reference

PTO & Hydraulics

Typesleeve hitchReference

Mid PTOindependentReference

Clutchmanual idler pulleyReference

Dimensions

Wheelbase111 cmReference

Weight227 kgReference

Front tire16x6.50-8Reference

Rear tire8-12Reference

Weight46 kgReference

Ag front4.80/4.00-8Reference

Ag rear6-12Reference

Lawn/turf front16x6.50-8Reference

Lawn/turf rear8-12Reference

Length160 cmReference

Width87 cmReference

Height98 cmReference

Front tread73 cmReference

Front tread76 cmReference

Rear tread68/83 cmReference

John Deere 110 attachments

38" mid-mount mower deckReference

snowblowerReference

bladeReference

front-end loaderReference

110 Serial Number Location

Serial number plate below the steering column on the Deere 110.Reference

110 Serial Numbers

19632550Reference

19643551Reference

196515001Reference

196640001Reference

196765001Reference

1968100001Reference

1969130001Reference

1970160000Reference

1971185001Reference

1972250001Reference

1973272001Reference

1974310001Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference

Battery volts12Reference

Battery AH24Reference

Attachment overview

38" mid-mount mower deckReference

SnowblowerReference

BladeReference

Front-end loaderReference

38" Mower deck

Typemid-mount John Deere 38Reference

Type3-blade, lift is manual or hydraulicReference

Cutting width96 cmReference

BeltM40223MReference

Overall width111 cmReference

Cut height3 to 8 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
