John Deere 110TLB
John Deere 110TLB — Backhoe loader tractor · 33 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
33 hp
Weight
3447 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Backhoe loader tractorReference
Four-wheel driveReference
Power steeringReference
Mechanical wet disc brakesReference
Four-post ROPS.Reference
Engine
Yanmar 2.2L 4-cyl dieselReference
Engine30.6 kWReference
Yanmar 4TNV88Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke88 x 90 mmReference
Power30.6 kWReference
Compression19:1Reference
Rated RPM2600Reference
Starter volts12Reference
Starter power2.0 kWReference
Oil capacity4.7 LReference
Coolant capacity9.5 LReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
PTO (claimed)24.6 kWReference
Hydraulic system56.8 LReference
Typeopen centerReference
Capacity56.8 LReference
Pressure206.8 barReference
Total flow89.3 lpmReference
Total flow46.2 lpmReference
Total flow61.7 lpmReference
Rear TypeIReference
Rear lift (at ends)1419 kgReference
Rear lift (at 24"/610mm)1134 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Capacities
Fuel57.9 LReference
Dimensions
Wheelbase181 cmReference
Weight3447 kgReference
Front tire10x16.5Reference
Rear tire17.5x24Reference
Industrial front10x16.5Reference
Industrial rear17.5x24Reference
Length751 cmReference
Width218 cmReference
Height (ROPS)256 cmReference
Operating weight3447 kgReference
Backhoe & Loader
Dig depth307 cmReference
Dump angle114 cmReference
110TLB Serial Number Location
Serial number plate on the right side of the 110TLB frame, above the front axle.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps40Reference
Charging amps55Reference
Battery CCA770Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
John Deere Backhoe
Backhoe typeJohn Deere BackhoeReference
Digging depth307 cmReference
2-Foot flat digging depth302 cmReference
8-Foot flat digging depth259 cmReference
Reach from pivot406 cmReference
Loading height257 cmReference
Bucket force2595 kgReference
Dipperstick force1707 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
