Lawn Tractor · 1966Unverified
John Deere 112
John Deere 112 — Model year 1966-19671968-1974 · 10 hp. Reference specifications; pending source verification.
The John Deere 112 is a lawn tractor with a rated power of 10 hp, situated at the lighter end of its class. Manufactured between 1966 and 1974, the 112 features a 1-cylinder petrol air-cooled engine paired with two-wheel drive and a 4-speed gearbox. The operating weight of the 112 is listed as 268 kg, and it is suitable for operations up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
10 hp
Weight
268 kg
Catalogue coverage
Variants represented
2
Richest spec table
61 rows
Recorded power
10 hp
Recorded weight
268 kg
Transmissions
4-speed gear with variable pulley drive
Production years
1966-1974
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Garden tractorReference
Built in Horicon, Wisconsin, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
112Hhydraulic liftReference
Engine
10HP Tecumseh 388cc 1-cyl gasolineReference
Tecumseh HH100Reference
gasolineReference
1-cylinderReference
air-cooled horizontal-shaftReference
Displacement23.7 ciReference
Bore/Stroke84 x 70 mmReference
Power7.5 kWReference
Rated RPM3600Reference
Idle RPM1200-3800Reference
Starter volts12Reference
Oil capacity0.9 LReference
Oil change25 hReference
Image courtesy of Ben CopenhaverReference
Transmission
4-speed gear with variable pulley driveReference
TransmissionPeerless 2300Reference
Typegear with variable pulley driveReference
Gears4 forward and 1 reverseReference
Oil capacity1.4 LReference
Oil change200 hReference
Four-speed gear shift with reverse using the combination brake-clutch foot pedal. Right-hand Variator lever allows on-the-move adjustment within a range of speeds for each gear.Reference
Capacities
Fuel7.2 LReference
PTO & Hydraulics
Hydraulic system4.7 LReference
Capacity4.7 LReference
Dimensions
Wheelbase111 cmReference
Weight268 kgReference
Front tire16x6.50-8Reference
Rear tire8-12Reference
Lawn/turf front16x6.50-8Reference
Lawn/turf rear8-12Reference
Length160 cmReference
Width93 cmReference
Height98 cmReference
Front tread76 cmReference
Rear tread68/83 cmReference
John Deere 112 attachments
38" mid-mount mower deckReference
46" mid-mount mower deckReference
snowblowerReference
112 Serial Number Location
Serial number plate located below steering column.Reference
112 Serial Numbers
19662551Reference
19673551Reference
1968100001Reference
1969130001Reference
1970160000Reference
1971185001Reference
1972250001Reference
1973260001Reference
1974300001Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
38" mid-mount mower deckReference
46" mid-mount mower deckReference
SnowblowerReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
