Tractor · 2003Unverified

John Deere 1247

Name: John Deere 1247
Brand: John Deere

John Deere 1247 — 47 Series · 37 hp. Reference specifications; pending source verification.

The John Deere 1247 is a compact tractor model with a rated power of 37 hp. Manufactured between 2003 and 2004, this model is equipped with a 3-cylinder diesel liquid-cooled engine, which powers a 12-speed gearbox with four-wheel drive. The John Deere 1247 is suited for tasks on areas of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

37 hp

Catalogue coverage

Variants represented

Richest spec table

41 rows

Recorded power

37 hp

Transmissions

12-speed synchronized

Production years

2003-2004

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

DistributorJohn DeereReference

ManufacturerGoldiniReference

Compact Utility tractorReference

Built in ItalyReference

Four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Hydraulic wet disc brakesReference

Two-post mid-mount folding ROPS.Reference

Engine

Lombardini 1.7L 3-cyl dieselReference

Engine27.6 kWReference

Lombardini LDW 1603Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.7 LReference

Bore/Stroke88 x 90 mmReference

Power27.6 kWReference

Air cleanerdryReference

Rated RPM2800Reference

Torque103.1 NmReference

Torque RPM1650Reference

StarterelectricReference

Starter volts12Reference

Transmission

12-speed synchronizedReference

TypesynchronizedReference

Gears12 forward and reverseReference

Clutch228mm mechanical dry discReference

PTO & Hydraulics

Pressure150.0 barReference

Pump flow29.9 lpmReference

Rear TypeI/INReference

Rear lift (at ends)1349 kgReference

Rear lift (at 24"/610mm)980 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Engine RPM540@2608Reference

Engine RPM1000@2620Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps55Reference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
