Tractor · 1970Unverified
John Deere 1420
John Deere 1420 — Orchard/Vineyard tractor · 43 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
43 hp
Weight
1065 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Orchard/Vineyard tractorReference
Built in Rosario, ArgentinaReference
Two-wheel driveReference
Manual steeringReference
Dry disc brakesReference
Open operator station.Reference
Engine
John Deere 2.7L 3-cyl dieselReference
Fuel tank57.2 LReference
Engine32.1 kWReference
John DeereReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.7 LReference
Bore/Stroke102 x 110 mmReference
Power32.1 kWReference
Rated RPM2200Reference
Starter volts12Reference
Oil capacity6.0 LReference
Coolant capacity10.0 LReference
Transmission
5-speedReference
Gears5 forward and 1 reverseReference
Clutchdry discReference
PTO & Hydraulics
Typeopen centerReference
Rear TypeIReference
Rear PTOcontinuousReference
Rear PTO Type540Reference
Dimensions
Wheelbase199 cmReference
Weight1065 kgReference
Front tire5.00x15Reference
Rear tire13.6x24Reference
Ag front5.00x15Reference
Ag rear13.6x24Reference
Length339 cmReference
Width127 cmReference
Height (hood)132 cmReference
Shipping weight1065 kgReference
Ground clearance32 cmReference
Electrical
Charging systemalternatorReference
Charging amps28Reference
Battery volts12Reference
Battery AH70Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
