Tractor · 1996Unverified
John Deere 1546F
John Deere 1546F — 46 Series · 43 hp. Reference specifications; pending source verification.
The John Deere 1546F is a tractor with a rating of approximately 43 hp, positioning it towards the lower end of its class. It was manufactured from 1996 to 2003. The 1546F features a 3-cylinder diesel liquid-cooled engine, paired with four-wheel drive and a 16-speed gearbox. Its listed operating weight is 2224 kg, and it is suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
43 hp
Weight
2224 kg
Catalogue coverage
Variants represented
2
Richest spec table
51 rows
Recorded power
43 hp
Recorded weight
2224 kg
Transmissions
16-speed synchronized
Production years
1996-2003
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
DistributorJohn DeereReference
ManufacturerGoldiniReference
Orchard/Vineyard tractorReference
Built in ItalyReference
Four-wheel driveReference
Differential lockelectro-hydraulic rearReference
Power steeringReference
Wet disc brakesReference
Two-post mid-mount folding ROPS.Reference
Engine
John Deere 2.9L 3-cyl dieselReference
Engine33.6 kWReference
John Deere 3029Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.9 LReference
Bore/Stroke106 x 110 mmReference
Power33.6 kWReference
Air cleanerdryReference
Rated RPM2300Reference
Torque167.1 NmReference
Torque RPM1300Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed synchronizedReference
8-speedReference
TypesynchronizedReference
Gears16 forward and 8 reverseReference
Gears8 forward and reverseReference
Four gears in two ranges with shuttle.Reference
PTO & Hydraulics
PTO (claimed)32.1 kWReference
Typeopen centerReference
Pressure180.0 barReference
Pump flow32.9 lpmReference
Pump flow50.0 lpmReference
Rear TypeII/IReference
Rear lift (at ends)2150 kgReference
Rear PTOindependentReference
Rear PTO Type540/540EReference
Dimensions
Wheelbase191 cmReference
Weight2224 kgReference
Front tire10.0/75-15.3Reference
Rear tire380/70R24Reference
Standard tires (ag)Front: 10.0/75-15.3. Rear: 380/70R24Reference
Length330 cmReference
Height (steering wheel)137 cmReference
Height (ROPS)216 cmReference
Max weight3299 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
