The John Deere 1635 is a compact tractor with a rated output of 59 hp, featuring a 3-cylinder diesel liquid-cooled engine. Produced between 1977 and 1979, this model is equipped with two-wheel drive and an 8-speed gearbox. Its intended application is in smaller-acreage operations of up to 200 ac. Specifications for this model are detailed in the accompanying table.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
59 hp
Catalogue coverage
Variants represented
2
Richest spec table
41 rows
Recorded power
59 hp
Transmissions
8-speed gear
Production years
1977-1979
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Utility tractorReference
Built in Getafe, SpainReference
Two-wheel driveReference
Power steeringReference
Disc brakesReference
Open operator station.Reference
Engine
John Deere 2.9L 3-cyl dieselReference
Fuel tank73.4 LReference
Engine44.1 kWReference
John DeereReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.9 LReference
Bore/Stroke106 x 110 mmReference
Power44.1 kWReference
StarterelectricReference
Starter volts12Reference
Oil capacity6.0 LReference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 4 reverseReference
PTO & Hydraulics
Rear PTOliveReference
Rear PTOindependentReference
Rear PTO Type540Reference
Rear PTO Type540/1000Reference
Dimensions
Front tire6.00-16Reference
Rear tire13.6-28Reference
Ag front6.00-16Reference
Ag front6.50-16Reference
Ag front7.50-16Reference
Ag rear13.6-28Reference
Ag rear14.9-28Reference
Ag rear14.9-30Reference
Ag rear16.9-3013.6-36Reference
Ag rear13.6-38Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps33Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
