Industrial Tractor · 1960Unverified
John Deere 2010 Wheel
John Deere 2010 Wheel — New Generation Series · 50 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
50 hp
Weight
5000 to 5350 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Industrial tractorReference
Built in Dubuque, Iowa, USAReference
Total built6133 (total)Reference
Total built3543 (diesel)Reference
Total built2590 (gas)Reference
Two-wheel driveReference
Final drivesbull gearReference
Steeringpower optionalReference
Differential mechanical dry disc brakesReference
Open operator station.Reference
Variants
2010ag tractorReference
2010Cag crawlerReference
Dimensions
2010 Wheelindustrial tractorReference
Wheelbase208 cmReference
Weight5000 to 5350 poundsReference
Front tire6.00-16Reference
Rear tire14.9-28Reference
Industrial front6.00-16Reference
Industrial rear14.9-28Reference
Industrial front6.50-16Reference
Industrial front7.50-16Reference
Industrial front9.00-16Reference
Industrial rear16.9-24Reference
Industrial rear12.4-28Reference
Industrial rear16.9-28Reference
Length312 cmReference
Width192 cmReference
Height (hood)140 cmReference
Height (exhaust)189 cmReference
Clearance (front axle)42 cmReference
Clearance (drawbar)30 cmReference
Front tread137 cmReference
Rear tread157 cmReference
Shipping2268 kgReference
Shipping2315 kgReference
Operating2379 kgReference
Operating2426 kgReference
Engine
John Deere 2.4L 4-cyl gasolineReference
John Deere 2.7L 4-cyl dieselReference
Engine (net)37.3 kWReference
John DeereReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.4 LReference
Bore/Stroke92 x 89 mmReference
Power (net)37.3 kWReference
Air cleaneroil bathReference
Compression7.9:1Reference
Rated RPM2500Reference
Torque155.0 NmReference
Torque RPM1500Reference
Starter volts12Reference
Oil capacity4.7 LReference
Coolant capacity11.4 LReference
dieselReference
Displacement2.7 LReference
Bore/Stroke98 x 89 mmReference
Pre-heatingglow plugsReference
Compression19:1Reference
Torque162.4 NmReference
Transmission
8-speed constant meshReference
8-speed two-speed power shiftReference
ManufacturerJohn DeereReference
Typeconstant meshReference
Gears8 forward and 3 reverseReference
Clutch279.4mm mechanical dry discReference
Oil capacity30.3 LReference
TransmissionJohn Deere H-L-RReference
Typetwo-speed power shiftReference
Clutch254mm hydraulic dry discReference
Oil capacity25.6 LReference
Four ranges with left-hand high-low power shift, plus reverse shuttle, for each range.Reference
Capacities
Fuel60.6 LReference
PTO & Hydraulics
Hydraulic system30.3 LReference
Typeopen centerReference
Capacity30.3 LReference
Valves0 or 1Reference
Rear TypeII/IReference
Rear PTOindependentReference
Clutchdry discReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@1900Reference
Engine RPM1000@1900Reference
John Deere 2010 attachments
bladeReference
front-end loaderReference
backhoeReference
2010 Serial Numbers
Location:Serial number plate on the right-hand side of the engine block.Reference
196010001Reference
196110991Reference
196221087Reference
196331250Reference
196444036Reference
196558186Reference
FAQ: How to read a serial number table.Reference
Electrical
Charging systemgeneratorReference
Battery volts12Reference
Attachment overview
BladeReference
Front-end loaderReference
BackhoeReference
The 2010 Wheel Loader used a front-mounted 24 GPM hydraulic pump for the loader. The model 82 snow plow was available in 7, 8 and 9 foot widths. The blade lift mechanism was either by hydraulic cylinder or cable attached to the rear rockshaft.Reference
John Deere 50 Backhoe
Backhoe typeJohn Deere 50 BackhoeReference
Digging depth411 cmReference
Reach from pivot617 cmReference
Swing Arc205°Reference
John Deere 51 Sideshift Backhoe
Backhoe typeJohn Deere 51 Sideshift BackhoeReference
Digging depth411 cmReference
Reach from pivot632 cmReference
Swing Arc180°Reference
Speeds
With 14.9-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
