Tractor · 1960Unverified
John Deere 2010C
John Deere 2010C — Agricultural Crawler tractor · 47 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
47 hp
Max power
29.0 kW
Weight
8387 to 9645 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Agricultural Crawler tractorReference
Built in Dubuque, Iowa, USAReference
DrivecrawlerReference
Steeringmultiple disc clutchesReference
Contracting band brakesReference
Open operator station. Optional ROPS canopy.Reference
Variants
2010ag tractorReference
2010Cag crawlerReference
Dimensions
2010 Wheelindustrial tractorReference
Weight8387 to 9645 poundsReference
14-inch tracksReference
Length286 cmReference
Width155 cmReference
Height (hood)137 cmReference
Height (exhaust)185 cmReference
Gauge121 cmReference
Shipping3804 kgReference
Shipping3851 kgReference
Operating4331 kgReference
Operating4374 kgReference
Engine
John Deere 2.4L 4-cyl gasolineReference
John Deere 2.7L 4-cyl dieselReference
John Deere 2.4L 4-cyl LP gasReference
Drawbar (tested)29.1 kWReference
John DeereReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.4 LReference
Bore/Stroke92 x 89 mmReference
Air cleaneroil bathReference
Compression7.9:1Reference
Rated RPM2500Reference
Starter volts12Reference
dieselReference
Displacement2.7 LReference
Bore/Stroke98 x 89 mmReference
LP gasReference
Power at rated engine speed35.4 kWReference
Max power29.0 kWReference
Power at rated engine speed35.6 kWReference
Max power29.1 kWReference
Transmission
8-speedReference
Gears8 forward and 4 reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)35.4 kWReference
PTO (tested)35.6 kWReference
Rear PTO Type540,1000Reference
Power at rated PTO speed28.8 kWReference
Power at rated PTO speed35.6 kWReference
2010C Serial Numbers
Location:Serial number on the right side of the engine. below the alternator.Reference
196010001Reference
196110999Reference
196221087Reference
196331250Reference
196444036Reference
196558186Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundpositiveReference
Battery volts12Reference
John Deere 2010C Tracks
Width35 cmReference
Length on ground183 cmReference
Area on ground1.3 m²Reference
Ground pressure0.3 barReference
Width25 cmReference
Width30 cmReference
Test results
NTTL 829: gasoline 8-speed crawlerReference
NTTL 830: diesel 8-speed crawlerReference
Gasoline 8-speed crawlerOctober 19 - 31, 1962Link: Nebraska Tractor Test 829 fileReference
PTO performanceReference
Fuel use15.1 l/hourReference
Fuel use12.1 l/hourReference
Drawbar performanceReference
Fuel use15.5 l/hourReference
Gear 3 used for power test.Reference
Max pull4578 kgReference
Gear 1 used for pull test.Reference
Diesel 8-speed crawlerOctober 23 - 31, 1962Link: Nebraska Tractor Test 830 fileReference
Fuel use12.9 l/hourReference
Max pull4664 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
