Tractor · 1965Unverified

John Deere 2020

Name: John Deere 2020
Brand: John Deere

John Deere 2020 — New Generation Series · 54 hp. Reference specifications; pending source verification.

The John Deere 2020 is a tractor with an approximate power rating of 54 hp, positioning it at the lower end of its class. It was manufactured from 1965 to 1971. Equipped with a 4-cylinder diesel liquid-cooled engine, the 2020 features two-wheel drive and a powershift transmission. Its operating weight is listed at 2617 kg, making it suitable for operations of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

54 hp

Max power

32.8 kW

Weight

2617 kg

Catalogue coverage

Variants represented

Richest spec table

153 rows

Recorded power

54 hp

Recorded weight

2617 kg

Transmissions

8-speed unsynchronized

Production years

1965-1971

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Row-Crop tractorReference

FactoriesDubuque, Iowa, USAReference

FactoriesMexicoReference

Original price was $5,800 in 1971Reference

Two-wheel driveReference

Final drivesplanetaryReference

Differential lockmechanical rearReference

Steeringpower assistReference

Differential hydraulic wet disc brakesReference

Open operator station.Reference

Variants

2020utilityReference

2020OorchardReference

Engine

John Deere 3.0L 4-cyl gasolineReference

John Deere 3.3L 4-cyl dieselReference

Drawbar (tested)34.2 kWReference

John DeereReference

gasolineReference

4-cylinderReference

liquid-cooledReference

Displacement3.0 LReference

Bore/Stroke98 x 98 mmReference

Air cleaneroil bathReference

Air cleanerdryReference

Compression7.5:1Reference

Rated RPM2500Reference

Starter volts12Reference

Oil capacity6.6 LReference

dieselReference

Displacement3.3 LReference

Bore/Stroke98 x 109 mmReference

Compression16.3:1Reference

Power at rated engine speed40.2 kWReference

Max power32.8 kWReference

Power at rated engine speed40.3 kWReference

Max power34.2 kWReference

Fuel TypeDieselReference

No of Cylinders4-cylinderReference

Rated engine speed2,500Reference

Bore and stroke3.86x4.33 inchesReference

Compression ratio16.7:1Reference

Cooling systemliquid-cooledReference

Transmission

8-speed unsynchronizedReference

16-speed two-speed power shiftReference

8-speed power shuttleReference

TransmissionJohn Deere collar shiftReference

TypeunsynchronizedReference

Gears8 forward and 4 reverseReference

Clutchdry discReference

Four gears (1-4) in two ranges (I/II) plus reverse (R) range.Reference

Typetwo-speed power shiftReference

Gears16 forward and 8 reverseReference

Four gears (1-4) in two ranges (I/II) plus reverse (R) range. Left-hand power shift lever on dash.Reference

Typepower shuttleReference

Four gears (1-4) in two ranges (I/II) with left-hand reverser lever. Reverse only available in low (I) range.Reference

forward and reverse options8 forward and 4 reverse | 16 forward and 8 reverseReference

Rear Axle Drive TypeplanetaryReference

PTO & Hydraulics

PTO (tested)40.3 kWReference

Hydraulic system37.9 LReference

Typeclosed centerReference

Capacity37.9 LReference

Pressure155.1 barReference

Pump flow39.7 lpmReference

Rear TypeIIReference

Rear PTOliveReference

Rear PTOindependentReference

Rear PTO Type540Reference

Rear PTO Type540/1000Reference

Mid PTOoptionalReference

Mid PTO Type1000Reference

Power at rated PTO speed36.0 kWReference

Power at rated PTO speed36.8 kWReference

Capacities

Fuel73.8 LReference

Dimensions

Wheelbase218 cmReference

Weight2617 kgReference

Front tire7.50-16Reference

Rear tire15.5-38Reference

Ag front7.50-16Reference

Ag rear15.5-38Reference

Ag front6.00-16Reference

Ag front9.00-10Reference

Ag front7.50-18Reference

Ag rear18.4-16AReference

Ag rear14.9-24Reference

Ag rear16.9-24Reference

Ag rear14.9-26Reference

Ag rear16.9-26Reference

Ag rear18.4-26Reference

Ag rear12.4-28Reference

Ag rear14.9-28Reference

Ag rear16.9-28Reference

Ag rear13.6-28Reference

Ag rear16.9-30Reference

Ag rear13.9-36Reference

Ag rear14.9-36Reference

Ag rear13.6-38Reference

Gas Operating weight2617 kgReference

Ballasted weight3372 kgReference

John Deere 2020 attachments

front-end loaderReference

2020 Serial Number Location

Serial number plate on the right side of the 2020 transmission housing.Reference

2020 Serial Numbers

1965014502Reference

1966014680Reference

1967042721Reference

1968065176Reference

1969082404Reference

1970102032Reference

1971117500Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Gas Batteries1Reference

Diesel Batteries2Reference

Battery volts12Reference

Battery AH70Reference

Battery Group24TReference

Battery size60 AHReference

Battery options2 | 2Reference

Attachment overview

John Deere 37 loaderReference

John Deere 47 loaderReference

Test results

NTTL 936: gasoline 8-speed 2WDReference

NTTL 938: diesel 8-speed 2WDReference

Gasoline 8-speed 2WDMay 3 - 13, 1966Link: Nebraska Tractor Test 936 fileReference

PTO performanceReference

Fuel use18.2 l/hourReference

Fuel use15.5 l/hourReference

Drawbar performanceReference

Fuel use18.5 l/hourReference

Gear 5 used for power test.Reference

Max pull2584 kgReference

Gear 2 used for pull test.Reference

Diesel 8-speed 2WDMay 7 - 17, 1966Link: Nebraska Tractor Test 938 fileReference

Fuel use13.2 l/hourReference

Fuel use11.4 l/hourReference

Fuel use13.6 l/hourReference

Max pull2516 kgReference

Gear 3 used for pull test.Reference

General

Make & ModelJohn DeereReference

Country of manufacturerRow-Crop tractor | Mannheim, Baden-Württemberg, GermanyReference

Power

Rated Power64 hpReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM540 (1.375)Reference

Steering & brakes

Brakeshydraulic wet discReference

Steering typepowerReference

Hydraulics

Hydraulics Typeclosed centerReference

Maximum operating pressure2,200 psiReference

Rear Hitch category (SAE designation)Category II/IReference

Rear Hitch Sensing Typeposition and depth controlReference

Dimensions & weight

Overall Height224 cmReference

Overall Length357.1 cmReference

Overall Width224 cmReference

Ground Clearance35.1 cmReference

Operator station

Cab AvailabilityAvailableReference

Cab Air conditioning, temperature differential4WDReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
