Tractor · 1965Unverified

John Deere 2020 Orchard

Name: John Deere 2020 Orchard
Brand: John Deere

John Deere 2020 Orchard — New Generation Series · 54 hp. Reference specifications; pending source verification.

The John Deere 2020 Orchard is a tractor model rated at 54 hp — making it one of the more compact options in its class. It was manufactured from 1965 to 1971. Power comes from a 4-cylinder diesel liquid-cooled engine, driving through two-wheel drive with a 8-speed gearbox. It is aimed at jobs of around up to 200 ac. The available specification table below shows both UK and US units.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

54 hp

Catalogue coverage

Variants represented

Richest spec table

54 rows

Recorded power

54 hp

Transmissions

8-speed gear

Production years

1965-1971

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Orchard/Vineyard tractorReference

Built in Dubuque, Iowa, USAReference

Two-wheel driveReference

Final drivesplanetaryReference

Power steeringReference

Hydraulic disc brakesReference

Open operator station.Reference

Variants

2020utilityReference

2020OorchardReference

Engine

John Deere 3.0L 4-cyl gasolineReference

John Deere 3.3L 4-cyl dieselReference

Fuel tank73.8 LReference

John DeereReference

gasolineReference

4-cylinderReference

liquid-cooledReference

Displacement3.0 LReference

Bore/Stroke98 x 98 mmReference

Compression7.5:1Reference

Rated RPM2500Reference

StarterelectricReference

Starter volts12Reference

Oil capacity5.7 LReference

Coolant capacity11.4 LReference

dieselReference

Displacement3.3 LReference

Bore/Stroke98 x 109 mmReference

Compression16.3:1Reference

Transmission

8-speed gearReference

TypegearReference

Gears8 forward and 4 reverseReference

Oil capacity37.9 LReference

PTO & Hydraulics

PTO (claimed)40.3 kWReference

Typeclosed centerReference

Pump flow49.2 lpmReference

Rear PTOliveReference

Rear PTO Type540Reference

Rear PTO Type540/1000Reference

Dimensions

Wheelbase198 cmReference

Front tire7.50-16Reference

Rear tire16.9-26Reference

Ag front7.50-16Reference

Ag rear16.9-26Reference

Ag rear18.4-26Reference

Length336 cmReference

Width197 cmReference

Height (steering wheel)165 cmReference

Height (hood)137 cmReference

Clearance (front axle)46 cmReference

Rear tread142 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Speeds

With 16.9-28 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
