Tractor · 2016Unverified
John Deere 2026R
John Deere 2026R — 2R Series · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
1676 to 2028 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Compact Utility tractorReference
Four-wheel driveReference
Final drivesspur gearReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab optional.Reference
Engine
Yanmar 1.1L 3-cyl dieselReference
Engine (gross)18.8 kWReference
Engine (net)17.7 kWReference
Yanmar 3TNV76Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.1 LReference
Bore/Stroke76 x 76 mmReference
Rated Power (net)17.7 kWReference
Rated Power (gross)18.8 kWReference
Air cleanerdryReference
Rated RPM3200Reference
Torque63.7 NmReference
Torque RPM1900Reference
StarterelectricReference
Starter volts12Reference
Oil capacity2.7 LReference
Coolant capacity3.7 LReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
PTO (claimed)13.4 kWReference
Hydraulic system14.4 LReference
Typeopen centerReference
Capacity14.4 LReference
Pressure137.9 barReference
Pump flow14.0 lpmReference
Total flow28.0 lpmReference
Steering flow14.0 lpmReference
Rear TypeIReference
Rear lift (at ends)560 kgReference
Rear lift (at 24"/610mm)400 kgReference
Rear PTOindependentReference
Clutchwet discReference
Rear PTO Type540 (1.375)Reference
Mid PTOindependentReference
Mid PTO Type2100Reference
Front PTOindependentReference
Front PTO Type2100Reference
Capacities
Fuel23.8 LReference
Max capacity1711 kgReference
Dimensions
Wheelbase160 cmReference
Weight1676 to 2028 poundsReference
Lawn/turf front210/65-R12Reference
Lawn/turf rear345/60-R15Reference
Lawn/turf front220/55-12Reference
Lawn/turf rear280/70-16Reference
Industrial front210/65-R12Reference
Industrial rear310/70-R16.5Reference
Length280 cmReference
Width119 cmReference
Height (ROPS)236 cmReference
Height (cab)200 cmReference
ROPS760 kgReference
Cab919 kgReference
Max front axle611 kgReference
Max rear axle1099 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Battery CCA500Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
