Tractor · 2017Unverified

John Deere 2038R

Name: John Deere 2038R
Brand: John Deere

John Deere 2038R — 2R Series · 37 hp. Reference specifications; pending source verification.

The John Deere 2038R is a compact tractor rated at 37 hp, manufactured in 2017. It features a 3-cylinder turbocharged diesel liquid-cooled engine, powering four-wheel drive through a hydrostatic transmission. The listed weight of this model ranges from 2436 to 2910 pounds. Its intended application is for jobs covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

37 hp

Max power

36.7 hp (2,500 rpm)

Weight

2436 to 2910 pounds

Catalogue coverage

Variants represented

Richest spec table

122 rows

Recorded power

37 hp

Transmissions

hydrostatic

Production years

2017-2017

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Compact Utility tractorReference

Built in Augusta, Georgia, USAReference

Original price$23,958 (2017)Reference

Original price$29,499 (2026)Reference

Four-wheel driveReference

Final drivesspur gearReference

Differential lockmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS.Reference

Engine

Yanmar 1.6L 3-cyl dieselReference

Fuel tank32.2 LReference

Engine (gross)27.8 kWReference

Yanmar 3TNV88C-NJTReference

turbocharged dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.6 LReference

Bore/Stroke86 x 90 mmReference

EmissionsTier IVReference

Power (gross)27.8 kWReference

Fuel systemdirect injectionReference

Air cleanerdual dry elementReference

Compression19.1:1Reference

Rated RPM2500Reference

StarterelectricReference

Starter volts12Reference

Starter power1.4 kWReference

Oil capacity4.5 LReference

Fuel TypeDieselReference

No of CylindersThreeReference

Rated engine speed2,500 rpmReference

Emissions complianceFinal Tier 4Reference

Cylinder linersCast-in-blockReference

Engine torque at rated speed104.7 NmReference

Injection pump typeDirect InjectionReference

AspirationTurbochargedReference

Bore and stroke86x90 mmReference

Compression ratio19.1:1Reference

Cooling systemWater pumpReference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverseReference

Transmission TypeE-HSTReference

Wheel Drive4WDReference

ClutchWet discReference

PTO & Hydraulics

PTO (claimed)22.7 kWReference

Typeopen centerReference

Pressure172.4 barReference

Valves0 to 3Reference

Pump flow20.1 lpmReference

Total flow35.2 lpmReference

Steering flow15.1 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at 24"/610mm)615 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Mid PTO Type2000Reference

Dimensions

Wheelbase172 cmReference

Weight2436 to 2910 poundsReference

Front tire7.00-12Reference

Rear tire12.4-16Reference

Ag front7.00-12Reference

Ag rear12.4-16Reference

Lawn/turf front23x8.50-14Reference

Lawn/turf rear14-17.5Reference

Lawn/turf front200/60R15Reference

Lawn/turf rear300/70R20Reference

Industrial front23x8.50-14Reference

Industrial rear14-17.5Reference

Shipping1104 kgReference

Operating1319 kgReference

Max front axle879 kgReference

Max rear axle1088 kgReference

John Deere 2038R attachments

60" mid-mount mower deckReference

72" mid-mount mower deckReference

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps85Reference

Charging volts12Reference

Battery CCA500Reference

Battery volts12Reference

Battery size500 CCAReference

Alternator size85 ampReference

Attachment overview

60" mid-mount mower deckReference

72" mid-mount mower deckReference

Front-end loaderReference

BackhoeReference

John Deere 270B Backhoe

Backhoe typeJohn Deere 270B BackhoeReference

General

Make & ModelYanmar® @ 3TNV88C-NJTReference

LubricationPressurizedReference

Cruise controlStandardReference

SCV controlJoystick: AvailableReference

Rollover protective structureType\\nFoldable\\nASABE S478Reference

PlatformSemi-flatReference

Capacities

Capacity95.8 cu in.Reference

Front Axle capacity880 kgReference

Rear Axle capacity1,799.9 kgReference

Crankcase oil volume4.5 LReference

Power

Max Power36.7 hp (2,500 rpm)Reference

PTO

PTO Power30.4 hpReference

Rear PTO PowerAvailableReference

Rear PTO ControlIndependentReference

Rear PTO RPM543 rpmReference

Mid PTOAvailableReference

Mid PTO RPM1,998 rpmReference

Steering & brakes

BrakesWet discReference

Steering typePower steeringReference

Hydraulics

Pump Rated Output (total)35.2 l/minReference

Hydraulics TypeDual gearReference

Maximum operating pressure2,495 psiReference

Remote ValvesthreeReference

Steering & Implements flow15 L/min (20.2 L/min)Reference

Rear Hitch category (SAE designation)3-Point | Category 1Reference

Dimensions & weight

Turning radius2.5 mReference

Overall weight1,320 kgReference

Operator station

Cab AvailabilityTrueReference

Seat SuspensionAvailableReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
