Tractor · 1981Unverified

John Deere 2040S

Name: John Deere 2040S
Brand: John Deere

John Deere 2040S — Utility tractor · 75 hp. Reference specifications; pending source verification.

The John Deere 2040S is a tractor with a rated power output of 75 hp, placing it in the middle of its class in terms of power. Manufactured between 1981 and 1987, this tractor features a 4-cylinder diesel liquid-cooled engine, driving through a powershift transmission with four-wheel drive. Its listed weight ranges from 7365 to 7995 pounds. It is suited for tasks on areas of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

75 hp

Weight

7365 to 7995 pounds

Catalogue coverage

Variants represented

Richest spec table

77 rows

Recorded power

75 hp

Recorded weight

3340 kg

Transmissions

8-speed partially synchronized

Production years

1981-1987

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Utility tractorReference

Built in Mannheim, Baden-Württemberg, GermanyReference

Two- or four-wheel driveReference

Final drivesplanetaryReference

Differential lockmechanical rearReference

Power steeringReference

Hydraulic wet disc brakesReference

SoundGard 2 Cab.Reference

Engine

John Deere 3.9L 4-cyl dieselReference

Fuel tank95.0 LReference

Engine (net)55.9 kWReference

John DeereReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.9 LReference

Bore/Stroke106 x 110 mmReference

Power (net)55.9 kWReference

Fuel systemdirect injectionReference

Air cleanerdryReference

Compression16.8:1Reference

Rated RPM2500Reference

Torque246.0 NmReference

Torque RPM1400Reference

Starter volts12Reference

Oil capacity8.5 LReference

Coolant capacity188.3 LReference

Transmission

8-speed partially synchronizedReference

16-speed two-speed power shiftReference

TransmissionSynchronReference

Typepartially synchronizedReference

Gears8 forward and 4 reverseReference

Clutchdry discReference

Oil capacity54.0 LReference

TransmissionPower SynchronReference

Typetwo-speed power shiftReference

Gears16 forward and 8 reverseReference

PTO & Hydraulics

PTO (claimed)49.2 kWReference

Typeclosed centerReference

Pressure170.0 barReference

Pump flow46.9 lpmReference

Rear TypeII/IReference

Controllower-link draft controlReference

Rear lift2549 kgReference

Rear PTOindependentReference

Clutchhydraulic discReference

Rear PTO Type540Reference

Rear PTO Type540/1000Reference

Engine RPM540@2400Reference

Engine RPM1000@2400Reference

Dimensions

2WD Wheelbase228 cmReference

4WD Wheelbase228 cmReference

Weight7365 to 7995 poundsReference

Front tire7.50-16Reference

Rear tire16.9-34Reference

2WD 11.2-28 4WD} Ag front7.50-16Reference

Ag rear16.9-34Reference

2WD Length373 cmReference

4WD Length386 cmReference

Width205 cmReference

Height (cab)264 cmReference

Height (exhaust)279 cmReference

2WD Shipping weight3340 kgReference

4WD Shipping weight3626 kgReference

2WD Clearance (front axle)66 cmReference

4WD Clearance (front axle)48 cmReference

2WD Front tread147 to 200 cmReference

4WD Front tread149 to 198 cmReference

Rear tread160 to 200 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps55Reference

Batteries2Reference

Battery volts12Reference

Battery AH66Reference

Speeds

With 16.9-34 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
