Tractor · 2009Unverified

John Deere 20C

Name: John Deere 20C
Brand: John Deere

John Deere 20C — Milenio C Series · 19 hp. Reference specifications; pending source verification.

The John Deere 20C is a tractor model with a rated power of 19 hp, categorising it as a lighter model within its class. Manufactured from 2009 to 2011, this model features a 3-cylinder diesel liquid-cooled engine, paired with an 8-speed gearbox. Its listed operating weight is 889 kg and it is suitable for operations of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

19 hp

Weight

889 kg

Catalogue coverage

Variants represented

Richest spec table

48 rows

Recorded power

19 hp

Recorded weight

889 kg

Transmissions

8-speed mechanical shuttle

Production years

2009-2011

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Compact Utility tractorReference

Power steeringReference

Two-post mid-mount folding ROPS.Reference

Engine

Yanmar 0.9L 3-cyl dieselReference

Fuel tank18.2 LReference

Engine (gross)13.8 kWReference

Engine (net)12.5 kWReference

Yanmar 3TNV70Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement0.9 LReference

Bore/Stroke70 x 74 mmReference

Rated Power (net)12.5 kWReference

Rated Power (gross)13.8 kWReference

Rated RPM2800Reference

Torque49.8 NmReference

Torque RPM1800Reference

Starter typeelectricReference

Transmission

8-speed mechanical shuttleReference

Typemechanical shuttleReference

Gears8 forward and reverseReference

Four gears in two ranges with reverser.Reference

PTO & Hydraulics

PTO (claimed)8.9 kWReference

Pressure150.0 barReference

Pump flow14.0 lpmReference

Rear TypeINReference

Rear lift (at 24"/610mm)249 kgReference

Rear PTO Type540/1000Reference

Dimensions

Weight889 kgReference

Front tire6.5/80x12Reference

Rear tire8.25x16Reference

Ag front6.5/80x12Reference

Ag rear8.25x16Reference

Ag rear250x80-16Reference

Lawn/turf front20x8-10Reference

Lawn/turf rear27x10.5-15Reference

Industrial front25x5.5-14Reference

Industrial rear15-19.5Reference

Length245 cmReference

Width103 cmReference

Height (ROPS)138 cmReference

Ground clearance24 cmReference

889 kgReference

Max front axle600 kgReference

Max rear axle800 kgReference

Capacities

Max capacity1399 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
