Tractor · 1982Unverified
John Deere 2141
John Deere 2141 — 41 Series · 76 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
76 hp
Weight
7800 to 8700 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Utility tractorReference
Built in Nigel, South AfricaReference
Two- or four-wheel driveReference
Steeringhydrostatic powerReference
Open operator station.Reference
Engine
ADE 3.9L 4-cyl dieselReference
Engine57.0 kWReference
ADEReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke98 x 127 mmReference
Power57.0 kWReference
Rated RPM2300Reference
Starter volts12Reference
Transmission
8-speedReference
Gears8 forward and 4 reverseReference
PTO & Hydraulics
Rear PTO Type540/1000Reference
Dimensions
Weight7800 to 8700 poundsReference
2WD Weight3538 kgReference
4WD Weight3946 kgReference
2141 Serial Numbers
Location:Serial number plate on the right side of the 2141 tractor frame, above the front axle.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
