The John Deere 2200 is a compact tractor with a power rating of 63 hp, positioning it within a specific category. Manufactured from 1993 to 1998, this model features a 4-cylinder diesel liquid-cooled engine, coupled with a 10-speed gearbox and four-wheel drive. The 2200 is suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
63 hp
Catalogue coverage
Variants represented
2
Richest spec table
37 rows
Recorded power
63 hp
Transmissions
10-speed gear
Production years
1993-1998
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
DistributorJohn DeereReference
ManufacturerZetorReference
Utility tractorReference
Built in Brno, Czech RepublicReference
Two- or four-wheel driveReference
Power steeringReference
Hydraulic disc brakesReference
Open platform. Cab optional.Reference
Engine
Zetor 3.6L 4-cyl dieselReference
Fuel tank70.0 LReference
Engine (net)47.0 kWReference
ZetorReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.6 LReference
Bore/Stroke102 x 110 mmReference
Rated Power (net)47.0 kWReference
Rated RPM2200Reference
Starter volts12Reference
Transmission
10-speed gearReference
TypegearReference
Gears10 forward and 2 reverseReference
PTO & Hydraulics
Typeopen centerReference
Pressure180.0 barReference
Valves1Reference
Pump flow40.1 lpmReference
Rear TypeIIReference
Controltop link draft sensingReference
Rear lift3568 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Rear PTO Type540/1000Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
