The John Deere 2330 is a compact tractor model with a rated output of 47 hp. It was manufactured from 1975 to 1980. The 2330 features a 3-cylinder diesel liquid-cooled engine, coupled with a two-wheel drive system and an 8-speed gearbox. The listed weight of this model is 3061 kg, with an estimated suitability for tasks covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
47 hp
Weight
3061 kg
Catalogue coverage
Variants represented
2
Richest spec table
48 rows
Recorded power
47 hp
Recorded weight
3061 kg
Transmissions
8-speed
Production years
1975-1980
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Orchard/Vineyard tractorReference
Built in Rosario, ArgentinaReference
Two-wheel driveReference
Manual steeringReference
Hydraulic wet disc brakesReference
Open operator station.Reference
Engine
John Deere 2.7L 3-cyl dieselReference
Engine39.1 kWReference
John DeereReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.7 LReference
Bore/Stroke102 x 110 mmReference
Power39.1 kWReference
Compression16.7:1Reference
Rated RPM2500Reference
Starter volts12Reference
Oil capacity5.7 LReference
Coolant capacity10.0 LReference
Transmission
8-speedReference
Gears8 forward and 4 reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)35.1 kWReference
Hydraulic system37.9 LReference
Typeopen centerReference
Capacity37.9 LReference
Rear TypeIReference
Rear PTOcontinuousReference
Rear PTO Type540Reference
Capacities
Fuel95.0 LReference
Dimensions
Wheelbase182 cmReference
Weight3061 kgReference
Front tire5.50x15Reference
Rear tire13.6x24Reference
Ag front5.50x15Reference
Ag rear13.6x24Reference
Length303 cmReference
Width249 cmReference
Height (steering wheel)140 cmReference
Height (hood)138 cmReference
Shipping weight3061 kgReference
Ground clearance24 cmReference
Electrical
Charging systemalternatorReference
Charging amps28Reference
Battery volts12Reference
Battery AH70Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
