The John Deere 2735 is a compact tractor with a rated output of 62 hp. It was manufactured from 1975 to 1983. The 2735 features a 4-cylinder diesel liquid-cooled engine, coupled with a two-wheel drive system and an 8-speed gearbox. Its listed weight is 3129 kg, and it is suited for tasks involving approximately 200 acres of land.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
62 hp
Weight
3129 kg
Catalogue coverage
Variants represented
2
Richest spec table
26 rows
Recorded power
62 hp
Recorded weight
3129 kg
Transmissions
8-speed
Production years
1975-1983
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Utility tractorReference
Built in Monterrey, MexicoReference
Two-wheel driveReference
Open operator station.Reference
Engine
John Deere 3.9L 4-cyl dieselReference
Engine46.0 kWReference
John DeereReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke106 x 110 mmReference
Power46.0 kWReference
Rated RPM2500Reference
Starter typeelectricReference
Transmission
8-speedReference
Transmissioncollar shiftReference
Gears8 forward and 4 reverseReference
PTO & Hydraulics
Rear TypeIIReference
Dimensions
Weight3129 kgReference
Front tire7.50-16Reference
Rear tire15.5-38Reference
Ag front7.50-16Reference
Ag rear15.5-38Reference
Ag rear18.4-30Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
