Tractor · 1983Unverified
John Deere 2750 Low-Profile
John Deere 2750 Low-Profile — Orchard/Vineyard tractor · 75 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
75 hp
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Orchard/Vineyard tractorReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD (optional)Reference
Differential lockrear standardReference
Steeringhydrostatic powerReference
Differential hydraulic wet disc brakesReference
Open operator station. Low-profile ROPS available.Reference
Variants
2750utility chassisReference
2750 High-Clearancehigh-cropReference
2750 Low-ProfileorchardReference
Engine
John Deere 3.9L 4-cyl dieselReference
Fuel tank98.4 LReference
John DeereReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke106 x 110 mmReference
Compression16.8:1Reference
Rated RPM2500Reference
Idle RPM1500-2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed partially synchronizedReference
16-speed partial powershiftReference
12-speed partially synchronizedReference
TransmissionJohn Deere Top-Shaft SynchronizedReference
Typepartially synchronizedReference
Gears8 forward and 4 reverseReference
Four gears in two ranges, plus reverse range. Synchronized shifting between gears.Reference
TransmissionJohn Deere Hi-Lo Top-Shaft SynchronizedReference
Typepartial powershiftReference
Gears16 forward and 8 reverseReference
Four gears (1-4) in two ranges (I-II) and reverse (R) with two-speed power shift (rabbit/turtle).Reference
TransmissionJohn Deere TSS CreeperReference
Gears12 forward and 8 reverseReference
PTO & Hydraulics
PTO (claimed)55.9 kWReference
Typeclosed centerReference
Pump flow87.1 lpmReference
Rear PTOindependentReference
Rear PTO Type540Reference
Rear PTO Type540/1000 (optional)Reference
Dimensions
2WD Wheelbase226 cmReference
4WD Wheelbase228 cmReference
Front tire27/9.5-15Reference
Rear tire18.4-16.1 (2WD)Reference
Standard tires (ag)Front: 27/9.5-15. Rear: 18.4-16.1 (2WD)Reference
Standard tires (ag)Front: 9.5-24. Rear: 16.9-28 (4WD)Reference
2WD Length352 cmReference
4WD Length347 cmReference
2WD Height (steering wheel)147 cmReference
4WD Height (steering wheel)160 cmReference
2WD Clearance (front axle)62 cmReference
4WD Clearance (front axle)48 cmReference
2750 Low-Profile Serial Numbers
Location:Right side of main tractor frame, above front axle.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Battery volts12Reference
Speeds
With 18.4-30 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
