The John Deere 2951 is a tractor. It was manufactured from 1987 to 1993. Power comes from a 4-cylinder turbocharged diesel liquid-cooled engine, driving through four-wheel drive with a hydrostatic transmission. Listed weight is 4581 kg, and it is aimed at jobs of around varies. Available dimensions and performance figures follow in both unit systems.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Weight
4581 kg
Catalogue coverage
Variants represented
2
Richest spec table
26 rows
Recorded weight
4581 kg
Transmissions
16-speed
Production years
1987-1993
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Utility tractorReference
Built in Nigel, South AfricaReference
Two- or four-wheel driveReference
Steeringhydrostatic powerReference
Open operator station. Two-post Roll-Gard ROPS optional.Reference
Engine
ADE 3.9L 4-cyl dieselReference
ADEReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke98 x 127 mmReference
Rated RPM2300Reference
Starter volts12Reference
Transmission
16-speedReference
TransmissionTop-Shaft SynchronizedReference
Gears16 forward and 8 reverseReference
PTO & Hydraulics
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Weight4581 kgReference
Operating weight4581 kgReference
Ballasted weight5010 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
