Industrial Tractor · 1961Unverified

John Deere 3010 Wheel

Name: John Deere 3010 Wheel
Brand: John Deere

John Deere 3010 Wheel — New Generation Series · 69 hp. Reference specifications; pending source verification.

The John Deere 3010 Wheel is an industrial tractor with a rating of approximately 69 horsepower, positioning it at the lighter end of its class. This model was in production from 1961 to 1963 and features a 4-cylinder diesel liquid-cooled engine paired with two-wheel drive and an 8-speed gearbox. The operating weight of the John Deere 3010 Wheel is listed as 5525 to 6012 pounds, and it is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

69 hp

Weight

5525 to 6012 pounds

Catalogue coverage

Variants represented

Richest spec table

100 rows

Recorded power

69 hp

Transmissions

8-speed partially synchronized

Production years

1961-1963

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Industrial tractorReference

Built in Waterloo, Iowa, USAReference

Total built840 (total)Reference

Total built648 (diesel)Reference

Total built192 (gas)Reference

Two-wheel driveReference

Final drivesplanetaryReference

Steeringhydraulic powerReference

Differntial hydraulic wet disc brakesReference

Open operator stationReference

Variants

3010ag tractorReference

Dimensions

3010 Wheelindustrial tractorReference

Wheelbase208 cmReference

Weight5525 to 6012 poundsReference

Front tire7.50-16Reference

Rear tire14.9-28Reference

Industrial front7.50-16Reference

Industrial rear14.9-28Reference

Length320 cmReference

Width193 cmReference

Height207 cmReference

Height (hood)151 cmReference

Ground clearance32 cmReference

Front tread142 cmReference

Rear tread152/203 cmReference

Shipping2506 kgReference

Shipping2606 kgReference

Operating2626 kgReference

Operating2727 kgReference

Engine

John Deere 3.3L 4-cyl gasolineReference

John Deere 4.2L 4-cyl dieselReference

Engine (net)51.8 kWReference

Plows4Reference

John DeereReference

gasolineReference

4-cylinderReference

liquid-cooledReference

Displacement3.3 LReference

Bore/Stroke102 x 102 mmReference

Power (net)48.1 kWReference

Air cleaneroil bathReference

Compression7.5:1Reference

Rated RPM2200Reference

Torque222.4 NmReference

Torque RPM900Reference

Starter volts12Reference

Oil capacity7.6 LReference

Coolant capacity18.0 LReference

dieselReference

Displacement4.2 LReference

Bore/Stroke105 x 121 mmReference

Power (net)51.8 kWReference

Pre-heatingether injectionReference

Compression16.4:1Reference

Torque242.7 NmReference

Torque RPM1500Reference

Starter volts24Reference

Transmission

8-speed partially synchronizedReference

TransmissionJohn Deere Syncro-RangeReference

Typepartially synchronizedReference

Gears8 forward and 3 reverseReference

Clutch304.8mm dry discReference

Oil capacity36.0 LReference

Synchro-Range requires the tractor to be stopped and clutch depressed to select one of four shift stations. Once a station is selected the tractor can be shifted on the move between the two forward gears (and single reverse in stations 1, 2, and 3) by using the clutch.Reference

Capacities

Fuel94.6 LReference

PTO & Hydraulics

Hydraulic system36.0 LReference

Typeclosed centerReference

Capacity36.0 LReference

Pressure137.9 barReference

Valves0 to 2Reference

Pump flow68.1 lpmReference

Rear TypeIIReference

Rear PTOindependent (optional)Reference

Rear PTO Type540/1000 (1.375)Reference

Front PTOindependent (optional)Reference

Front PTO Type1000Reference

John Deere 3010 attachments

bladeReference

front-end loaderReference

backhoeReference

3010 Serial Numbers

Location:Rear of transmission caseReference

19611000Reference

196219801Reference

196332400Reference

FAQ: How to read a serial number table.Reference

Electrical

Groundpostitive (12V)Reference

Groundfloating (24V)Reference

Gas Batteries2Reference

Diesel Batteries4Reference

Battery volts6Reference

Attachment overview

BladeReference

Front-end loaderReference

BackhoeReference

John Deere 50 Backhoe

Backhoe typeJohn Deere 50 BackhoeReference

Digging depth411 cmReference

Reach from pivot502 cmReference

Swing Arc205°Reference

John Deere 51 Backhoe

Backhoe typeJohn Deere 51 BackhoeReference

Digging depth411 cmReference

Reach from pivot502 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
