Tractor · 2017Unverified
John Deere 3025E
John Deere 3025E — 3E Series · 24 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Weight
1007 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Compact Utility tractorReference
Built in Augusta, Georgia, USAReference
Original price$17,324 (2017 )Reference
Original price$18,330 (2020 )Reference
Four-wheel driveReference
Final drivesspur gearReference
Differential lockmechanical rearReference
Power steeringReference
Two-post folding ROPS.Reference
Engine
Yanmar 1.6L 3-cyl dieselReference
Fuel tank23.5 LReference
Engine (gross)18.2 kWReference
Yanmar 3TNV88FReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Bore/Stroke88 x 90 mmReference
EmissionsTier 4Reference
Power (gross)18.2 kWReference
Fuel systemhigh-pressure common rail direct injectionReference
Air cleanerdual dry elementReference
Compression19.1:1Reference
Rated RPM2400Reference
Idle RPM950-2550Reference
StarterelectricReference
Starter volts12Reference
Starter power1.4 kWReference
Oil capacity4.4 LReference
Coolant capacity4.9 LReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
PTO (claimed)13.0 kWReference
Typeopen centerReference
Pressure172.4 barReference
Valves0 to 2Reference
Pump flow20.1 lpmReference
Total flow35.2 lpmReference
Steering flow15.1 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at 24"/610mm)615 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2500Reference
Dimensions
Wheelbase152 cmReference
Weight1007 kgReference
Front tire7-14Reference
Rear tire11.2-24Reference
Weight350 kgReference
Ag front7-14Reference
Ag rear11.2-24Reference
Lawn/turf front27x8.5-15Reference
Lawn/turf rear41x14-20Reference
Industrial front25x8.5-14Reference
Industrial rear15-19.5Reference
Length387 cmReference
Height (ROPS)242 cmReference
Shipping1007 kgReference
Max front axle798 kgReference
Max rear axle1197 kgReference
John Deere 3025E attachments
front-end loaderReference
backhoeReference
3025E Serial Number Location
Serial number plate on the right side of the tractor frame, above the front axle.Reference
3025E Serial Numbers
20133025ExDHxxxxxxReference
20143025ExEHxxxxxxReference
20153025ExFHxxxxxxReference
20163025ExxGxxxxxxReference
20173025ExxHxxxxxxReference
20183025ExxJxxxxxxReference
20193025ExxKxxxxxxReference
20203025ExxLxxxxxxReference
20213025ExxMxxxxxxReference
20223025ExxNxxxxxxReference
20233025ExxPxxxxxxReference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps75Reference
Charging volts12Reference
Battery CCA500Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
John Deere 370B Backhoe
Backhoe typeJohn Deere 370B BackhoeReference
Transport height200 cmReference
Bucket width20 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
Digging depth208 cmReference
Reach from pivot297 cmReference
Loading height179 cmReference
Bucket Rotation176°Reference
Swing Arc148°Reference
Bucket force1221 kgReference
Dipperstick force715 kgReference
Speeds
With 15.00-19.5 R4 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
