Tractor · 2008Unverified
John Deere 3038E
John Deere 3038E — Model year 2008-20122013-2023 · 37 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
37 hp
Weight
986 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Compact Utility tractorReference
Built in Augusta, Georgia, USAReference
Original price$14,869 (2009 )Reference
Original price$20,669 (2016 )Reference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Yanmar 1.5L 3-cyl dieselReference
Engine (gross)27.7 kWReference
Engine27.1 kWReference
Yanmar 3TNV84TReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke84 x 90 mmReference
Power27.1 kWReference
Power (gross)27.7 kWReference
Air cleanerdry typeReference
Compression19:1Reference
Rated RPM2500Reference
Torque120.0 NmReference
Torque RPM1680Reference
Starter volts12Reference
Starter power1.4 kWReference
Coolant capacity4.2 LReference
Oil capacity4.5 LReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
Oil capacity20.8 LReference
Mechanically-controlled two-range hydrostatic transmission. Tractor must be stopped before shifting ranges.Reference
PTO & Hydraulics
PTO (claimed)22.4 kWReference
Hydraulic system20.8 LReference
Typeopen centerReference
Capacity20.8 LReference
Pressure172.4 barReference
Pump flow20.1 lpmReference
Total flow35.2 lpmReference
Steering flow15.1 lpmReference
Steering press.103.4 barReference
Rear Type1Reference
Rear lift (at 24"/610mm)615 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Capacities
Fuel24.2 LReference
Dimensions
Wheelbase152 cmReference
Weight986 kgReference
Front tire7.00-14Reference
Rear tire11.2-24Reference
Ag front7.00-14Reference
Ag rear11.2-24Reference
Lawn/turf front27x8.5-15Reference
Lawn/turf rear41x14.0-20Reference
Industrial front25x8.5-14Reference
Industrial rear15.00-19.5Reference
Length281 cmReference
Width143 cmReference
Width147 cmReference
Height (hood)129 cmReference
Height (ROPS)209 cmReference
Operating weight986 kgReference
Max weight2000 kgReference
John Deere 3038E attachments
front-end loaderReference
3038E Serial Number Location
Serial number plate on the right side of the tractor frame, above the front axle.Reference
3038E Serial Numbers
20093038E110001 (with loader)Reference
20093038E140001 (no loader)Reference
20103038E210001 (with loader)Reference
20103038E240001 (no loader)Reference
20113038ExBHxxxxxxReference
20123038ExCHxxxxxxReference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps40Reference
Battery CCA500Reference
Battery volts12Reference
Battery Group22NFReference
Attachment overview
John Deere 305 loaderReference
John Deere D160 loaderReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
