Backhoe Loader · 1971Unverified
John Deere 310
John Deere 310 — Backhoe loader tractor · 52 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
52 hp
Weight
5783 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Backhoe loader tractorReference
Two-wheel driveReference
Power steeringReference
Wet disc brakesReference
Open operator station. Available ROPS and cab, with optional heater.Reference
Engine
John Deere 2.7L 3-cyl dieselReference
John Deere 2.7L 3-cyl gasolineReference
Engine (gross)38.8 kWReference
Engine (net)39.7 kWReference
John DeereReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.7 LReference
Bore/Stroke102 x 110 mmReference
Power (net)39.7 kWReference
Air cleanerdryReference
Pre-heatingether injectionReference
Compression16.2:1Reference
Rated RPM2500Reference
Torque174.9 NmReference
Torque RPM1300Reference
Oil capacity11.4 LReference
Coolant capacity6.6 LReference
Coolant capacity8.5 LReference
Intake valve clearance0.356 mmReference
Exhaust valve clearance0.457 mmReference
gasolineReference
Power (net)37.3 kWReference
Power (gross)38.8 kWReference
Compression7.5:1Reference
Exhaust valve clearance0.559 mmReference
Transmission
8-speedReference
Transmissioncollar shiftReference
Gears8 forward and 4 reverseReference
Oil capacity77.6 LReference
Capacities
Fuel73.8 LReference
PTO & Hydraulics
Hydraulic system77.6 LReference
Typeclosed centerReference
Capacity77.6 LReference
Pressure162.0 barReference
Pump flow106.0 lpmReference
Dimensions
Wheelbase195 cmReference
Weight5783 kgReference
Ag front7.50-16Reference
Ag front11L-15Reference
Ag rear16.9-24Reference
Ag rear19.5L-24Reference
Length365 cmReference
Width210 cmReference
Height (exhaust)264 cmReference
Height (backhoe)342 cmReference
Front tread157 cmReference
Rear tread165 cmReference
Backhoe & Loader
Dig depth459 cmReference
Dump angle127 cmReference
Electrical
Charging systemalternatorReference
Batteries2Reference
Battery volts6Reference
Attachment overview
Front-end loaderReference
BackhoeReference
John Deere Backhoe
Backhoe typeJohn Deere BackhoeReference
Transport height342 cmReference
Digging depth459 cmReference
2-Foot flat digging depth429 cmReference
Reach from pivot520 cmReference
Loading height314 cmReference
Swing Arc180°Reference
Bucket force4762 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
