Backhoe Loader · 1982Unverified
John Deere 310B
John Deere 310B — Backhoe loader tractor · 65 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
65 hp
Weight
5987 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Backhoe loader tractorReference
Built in Dubuque, Iowa, USAReference
Two-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Four-post ROPS/FOPS. Cab optional with available heater.Reference
Engine
John Deere 3.6L 4-cyl dieselReference
Engine (gross)48.5 kWReference
Engine (net)46.2 kWReference
John DeereReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.6 LReference
Bore/Stroke102 x 110 mmReference
Power (net)46.2 kWReference
Power (gross)48.5 kWReference
Air cleanerdryReference
Compression16.2:1Reference
Rated RPM2500Reference
Torque217.0 NmReference
Torque RPM1300Reference
Starter volts12Reference
Oil capacity8.5 LReference
Coolant capacity11.4 LReference
Intake valve clearance0.356 mmReference
Exhaust valve clearance0.457 mmReference
Transmission
8-speed power shuttleReference
Typepower shuttleReference
Gears8 forward and reverseReference
Clutch254mm discReference
Oil capacity32.2 LReference
Capacities
Fuel73.8 LReference
PTO & Hydraulics
Hydraulic system77.6 LReference
Typeclosed centerReference
Capacity77.6 LReference
Pressure160.0 barReference
Total flow143.8 lpmReference
Dimensions
Wheelbase208 cmReference
Weight5987 kgReference
Front tire7.50/8.00-16Reference
Rear tire16.9-24Reference
Industrial front7.50/8.00-16Reference
Industrial rear16.9-24Reference
Industrial front11L-15Reference
Industrial rear19.5L-24Reference
Length718 cmReference
Width208 cmReference
Height342 cmReference
Height (backhoe)302 cmReference
Front tread147 cmReference
Rear tread165 cmReference
Backhoe & Loader
Dig depth444 cmReference
Dump angle127 cmReference
Electrical
Charging systemalternatorReference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
John Deere Backhoe
Backhoe typeJohn Deere BackhoeReference
Transport height302 cmReference
Digging depth444 cmReference
2-Foot flat digging depth439 cmReference
8-Foot flat digging depth408 cmReference
Reach from pivot528 cmReference
Swing Arc180°Reference
Bucket force4354 kgReference
Dipperstick force2721 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
