Backhoe Loader · 2001Unverified
John Deere 310G
John Deere 310G — Backhoe loader tractor · 78 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
78 hp
Weight
12800 to 15090 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Backhoe loader tractorReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD (optional)Reference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
ROPS canopy; cab with heat and A/C optionalReference
Engine
John Deere 4.5L 4-cyl dieselReference
Engine58.2 kWReference
John Deere 4045DReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.5 LReference
Power54.4 kWReference
Rated RPM2000Reference
Torque292.9 NmReference
Torque RPM1400Reference
Starter volts12Reference
Oil capacity8.5 LReference
Coolant capacity16.1 LReference
John Deere 4045TReference
turbocharged dieselReference
Power58.2 kWReference
Torque339.0 NmReference
Oil capacity13.0 LReference
Transmission
4-speedReference
Gears4 forward and reverseReference
Oil capacity15.1 LReference
Capacities
Fuel136.3 LReference
PTO & Hydraulics
Hydraulic system90.8 LReference
Typeopen centerReference
Capacity90.8 LReference
Pressure249.9 barReference
Pressure189.6 barReference
Total flow106.0 lpmReference
Dimensions
Wheelbase210 cmReference
Weight12800 to 15090 poundsReference
Front tire11L-15Reference
Rear tire16.9-24Reference
Industrial front11L-15Reference
Industrial rear16.9-24Reference
Industrial front11L-16Reference
Industrial front12-16.5Reference
Industrial rear19.5L-24Reference
Length708 cmReference
Width218 cmReference
Height (ROPS)274 cmReference
Operating weight5806 kgReference
Operating weight6844 kgReference
Ground clearance30 cmReference
Backhoe & Loader
Dig depth171 to 215 inchesReference
Electrical
Charging systemalternatorReference
Charging amps70Reference
Charging amps90 (optional)Reference
Batteries1Reference
Batteries2 (optional)Reference
Battery CCA950Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
John Deere Backhoe
Backhoe typeJohn Deere BackhoeReference
Digging depth434 cmReference
Digging depth (extended stick)546 cmReference
Reach from pivot543 cmReference
Reach from pivot (extended stick)652 cmReference
Loading height332 cmReference
Loading height (extended stick)424 cmReference
Bucket force5037 kgReference
Dipperstick force3177 kgReference
Speeds
With 19.L-24 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
