Backhoe Loader · 2001Unverified
John Deere 310SG
John Deere 310SG — Backhoe loader tractor · 91 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
91 hp
Weight
13500 to 15955 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Backhoe loader tractorReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD (optional)Reference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
ROPS canopy; cab with heat and A/C optionalReference
Engine
John Deere 4.5L 4-cyl dieselReference
Engine67.9 kWReference
John Deere 4045TReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.5 LReference
Power67.9 kWReference
Rated RPM2000Reference
Torque374.3 NmReference
Torque RPM1400Reference
Starter volts12Reference
Oil capacity13.0 LReference
Coolant capacity16.1 LReference
Transmission
4-speedReference
4-speed full power shiftReference
Gears4 forward and reverseReference
Oil capacity15.1 LReference
TransmissionPowerShiftReference
Typefull power shiftReference
Gears4 forward and 3 reverseReference
Capacities
Fuel136.3 LReference
PTO & Hydraulics
Hydraulic system90.8 LReference
Typeopen centerReference
Capacity90.8 LReference
Pressure249.9 barReference
Pressure249.9 barReference
Total flow138.5 lpmReference
Dimensions
Wheelbase210 cmReference
Weight13500 to 15955 poundsReference
Front tire11L-15Reference
Rear tire16.9-24Reference
Industrial front11L-15Reference
Industrial rear16.9-24Reference
Industrial front11L-16Reference
Industrial front12.5/80-18Reference
Industrial rear19.5L-24Reference
Length716 cmReference
Width218 cmReference
Height (ROPS)279 cmReference
Operating weight6123 kgReference
Operating weight7237 kgReference
Ground clearance33 cmReference
Backhoe & Loader
Dig depth174 to 221 inchesReference
Electrical
Charging systemalternatorReference
Charging amps90Reference
Batteries1Reference
Batteries2 (optional)Reference
Battery CCA950Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
John Deere Backhoe
Backhoe typeJohn Deere BackhoeReference
Digging depth441 cmReference
Digging depth (extended stick)561 cmReference
Reach from pivot556 cmReference
Reach from pivot (extended stick)668 cmReference
Loading height342 cmReference
Loading height (extended stick)429 cmReference
Bucket force5438 kgReference
Bucket force6911 kgReference
Dipperstick force3669 kgReference
Speeds
With 19.L-24 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
