The John Deere 3110 is a compact tractor, with a rated output of 55 hp. It was manufactured from 1998 to 2002. Powered by a 3-cylinder electric liquid-cooled engine, the tractor transmits power to all four wheels via a hydrostatic transmission. The listed weight is 3111 kg, suitable for tasks on areas up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
55 hp
Weight
3111 kg
Catalogue coverage
Variants represented
2
Richest spec table
40 rows
Recorded power
55 hp
Recorded weight
3111 kg
Transmissions
20-speed synchronized
Production years
1998-2002
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
DistributorJohn DeereReference
ManufacturerRenaultReference
Utility tractorReference
Built in Le Mans, FranceReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Cab standard with heat.Reference
Engine
John Deere 2.9L 3-cylReference
Fuel tank115.1 LReference
Engine (net)41.0 kWReference
John DeereReference
3-cylinderReference
liquid-cooledReference
Displacement2.9 LReference
Bore/Stroke106 x 110 mmReference
Rated Power (net)41.0 kWReference
Rated RPM2280Reference
StarterelectricReference
Starter volts12Reference
Transmission
20-speed synchronizedReference
20-speed power shiftReference
TypesynchronizedReference
Gears20 forward and reverseReference
TransmissionTwinshiftReference
Typepower shiftReference
PTO & Hydraulics
Pump flow51.9 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift2810 kgReference
Rear PTO Type540Reference
Dimensions
Wheelbase224 cmReference
Weight3111 kgReference
Front tire11.2R28Reference
Rear tire13.6R36Reference
Standard tires (ag)Front: 11.2R28. Rear: 13.6R36Reference
Length373 cmReference
Height (cab)245 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
