Tractor · 1985Unverified
John Deere 3150
John Deere 3150 — Utility tractor · 96 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
96 hp
Max power
61.1 kW
Weight
5338 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Utility tractorReference
Built in Mannheim, Baden-Württemberg, GermanyReference
Original price was $44,000 in 1987Reference
The John Deere 3150 was the first Deere tractor to feature mechanical front-wheel drive as standard equipment.Reference
Four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab optional.Reference
Engine
John Deere 5.9L 6-cyl dieselReference
Drawbar (claimed)61.9 kWReference
Drawbar (tested)61.1 kWReference
John DeereReference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.9 LReference
Bore/Stroke106 x 110 mmReference
Air cleanerpaper elementsReference
Compression17.8:1Reference
Rated RPM2400Reference
Starter volts12Reference
Coolant capacity17.0 LReference
Power at rated engine speed71.6 kWReference
Max power61.1 kWReference
Transmission
16-speed two-speed power shiftReference
TransmissionTop Shaft Synchronized Hi-Lo (TSS)Reference
Typetwo-speed power shiftReference
Gears16 forward and 8 reverseReference
Four gears in two ranges, plus reverse range, with two-speed power shift.Reference
PTO & Hydraulics
PTO (claimed)70.8 kWReference
PTO (tested)71.6 kWReference
Hydraulic system46.9 LReference
Typeclosed centerReference
Capacity46.9 LReference
Valves2Reference
Pump flow83.3 lpmReference
Rear TypeIIReference
Rear lift2857 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Engine RPM540@2400Reference
Engine RPM1000@2400Reference
Capacities
Fuel134.0 LReference
Dimensions
Wheelbase258 cmReference
Weight5338 kgReference
Front tire13.6-28Reference
Rear tire18.4-38Reference
Ag front13.6-28Reference
Ag rear18.4-38Reference
Operating weight5338 kgReference
Ballasted weight5579 kgReference
Front tread169 to 210 cmReference
Rear tread157 to 241 cmReference
John Deere 3150 attachments
front-end loaderReference
3150 Serial Numbers
Location:Serial number plate on the right side of the frame, above the front axle.Reference
1985532000Reference
1986562001Reference
1987587950Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Batteries2Reference
Battery CCA610Reference
Battery volts12Reference
Test results
Diesel 16-speed 4WDApril 1 - 14, 1986Link: Nebraska Tractor Test 1589 fileReference
PTO performanceReference
Fuel use22.0 l/hourReference
Drawbar performanceReference
Gear 5L used for power test.Reference
Max pull4765 kgReference
Gear 2H used for pull test.Reference
Speeds
With 18.4-38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
