Tractor · 1986Unverified
John Deere 3350
John Deere 3350 — Utility tractor · 91 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
91 hp
Weight
9315 to 10880 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Utility tractorReference
FactoriesMannheim, Baden-Württemberg, GermanyReference
FactoriesRosario, ArgentinaReference
Two- or four-wheel driveReference
Final drivesplanetaryReference
Differential lockmechanical rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Sound-Gard (SG2) Cab standard with optional air-conditioning. Open operator station in some markets.Reference
Engine
John Deere 5.9L 6-cyl dieselReference
Engine74.6 kWReference
John Deere 6359 DL008Reference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.9 LReference
Bore/Stroke107 x 110 mmReference
Power74.6 kWReference
Air cleanerdryReference
Compression17.4:1Reference
Rated RPM2300Reference
Torque370.1 NmReference
Torque RPM1400Reference
Starter volts12Reference
Starter power3.0 kWReference
Oil capacity11.5 LReference
Coolant capacity19.0 LReference
Transmission
16-speedReference
8-speedReference
TransmissionPower SynchronReference
Gears16 forward and 8 reverseReference
Gears8 forward and 4 reverseReference
PTO & Hydraulics
PTO (claimed)67.9 kWReference
Hydraulic system49.0 LReference
Hydraulic system52.0 LReference
Typeclosed center constant pressureReference
Capacity49.0 LReference
Capacity52.0 LReference
Pressure186.0 barReference
Total flow44.0 lpmReference
Rear TypeII/IIINReference
2WD Rear lift (at ends)4076 kgReference
4WD Rear lift (at ends)4898 kgReference
Front HitchIIReference
Front lift (at ends)1630 kgReference
Front lift (at ends)2960 kgReference
Rear PTOindependentReference
Clutchhydraulic wet discReference
Rear PTO Type540/1000Reference
Engine RPM540@2070Reference
Engine RPM1000@2172Reference
Front PTOindependentReference
Front PTO Type1000Reference
Capacities
Fuel121.1 LReference
Fuel173.0 LReference
4WD Max capacity7499 kgReference
Dimensions
2WD Wheelbase225 cmReference
4WD Wheelbase258 cmReference
Weight9315 to 10880 poundsReference
Front tire10.00-16Reference
2WD Rear tire18.4-38Reference
2WD Standard tires (ag)Front: 10.00-16. Rear: 18.4-38Reference
4WD Standard tires (ag)Front: 13.6-28. Rear: 18.4-38Reference
Length478 cmReference
Width203 cmReference
Height (cab)284 cmReference
Height (cab)270 cmReference
4WD Ground clearance53 cmReference
2WD Ground clearance68 cmReference
2WD Front tread144 to 209 cmReference
4WD Front tread151 to 200 cmReference
Rear tread150 to 199 cmReference
2WD4225 kgReference
4WD4935 kgReference
Electrical
GroundnegativeReference
Charging amps55Reference
Batteries2Reference
Battery volts12Reference
Battery AH88Reference
Speeds
With 18.4-38 rear tires.Reference
With 18.4-34 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
