Tractor · 1975Unverified
John Deere 3380
John Deere 3380 · 68 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
68 hp
Weight
4599 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Built in Welshpool, AustraliaReference
Total built1,521Reference
Two-wheel driveReference
Power steeringReference
Sedan cab with heat and air-conditioning.Reference
Variants
3380Abuilt 1975-1983Reference
3380Bbuilt 1983-1985Reference
Engine
John Deere 3.9L 4-cyl dieselReference
Engine54.4 kWReference
John Deere naturalReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke106 x 110 mmReference
Power54.4 kWReference
Compression16.8:1Reference
Rated RPM2500Reference
Torque245.4 NmReference
Torque RPM1450Reference
Starter typeelectricReference
Transmission
12-speedReference
TransmissionHi-LoReference
Gears12 forward and 4 reverseReference
PTO & Hydraulics
PTO (claimed)50.7 kWReference
Typeopen centerReference
Valves1Reference
Pump flow59.8 lpmReference
Rear TypeIIReference
Rear PTOliveReference
Rear PTO Type540Reference
Engine RPM540@1970Reference
Dimensions
Weight4599 kgReference
Front tire9.00-16Reference
Rear tire23.1-26Reference
Ag front9.00-16Reference
Ag rear23.1-26Reference
Length430 cmReference
Width243 cmReference
Height (exhaust)260 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
