Snowmobile · 1975Unverified
John Deere 340/S
John Deere 340/S — Snowmobile · 47 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
47 hp
Weight
174 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
SnowmobileReference
Built in Horicon, Wisconsin, USAReference
TrackedReference
Manual steeringReference
Hydraulic disc brakesReference
Suspensionslide railReference
Engine
47HP Kioritz 339cc 2-cyl gasolineReference
Fuel tank30.3 LReference
Kioritz KEC 340 RS/2Reference
gasolineReference
2-cylinderReference
air-cooledReference
Displacement20.7 ciReference
Bore/Stroke60 x 60 mmReference
Power35.0 kWReference
Fuel systemdual Mikuni VM34-55 carburetorsReference
Rated RPM8000Reference
Starter typemanual-recoilReference
SparkplugChampion N19-VReference
Dimensions
Weight174 kgReference
Length262 cmReference
Width85 cmReference
Height104 cmReference
Track width39 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
