Industrial Tractor · 1970Unverified
John Deere 350B
John Deere 350B — Industrial Crawler tractor · 46 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
46 hp
Weight
7825 to 7895 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Industrial Crawler tractorReference
Built in Dubuque, Iowa, USAReference
DrivecrawlerReference
Steeringclutch-brake systemReference
Contracting band brakesReference
Open operator station.Reference
Engine
John Deere 2.5L 3-cyl dieselReference
John Deere 2.2L 3-cyl gasolineReference
Fuel tank83.3 LReference
Engine (gross)34.3 kWReference
Engine (net)31.3 kWReference
Drawbar (claimed)22.4 kWReference
John DeereReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke98 x 110 mmReference
Power (net)31.3 kWReference
Power (gross)34.3 kWReference
Air cleanerdryReference
Compression16.7:1Reference
Rated RPM2500Reference
Idle RPM750-2650Reference
Operating RPM1300-2500Reference
Torque149.2 NmReference
Torque RPM1300Reference
StarterelectricReference
Starter volts12Reference
Oil capacity8.5 LReference
Coolant capacity11.4 LReference
gasolineReference
Displacement2.2 LReference
Bore/Stroke98 x 98 mmReference
Compression7.7:1Reference
Transmission
4-speed gearReference
4-speed shuttleReference
TypegearReference
Gears4 forward and 1 reverseReference
Oil capacity8.5 LReference
TypeshuttleReference
Gears4 forward and reverseReference
PTO & Hydraulics
Total flow56.8 lpmReference
Total flow94.6 lpmReference
Rear PTOtransmissionReference
Rear PTO Type540Reference
Dimensions
Weight7825 to 7895 poundsReference
12-inch tracksReference
Length246 cmReference
Length251 cmReference
6300 dozer length335 cmReference
6305 dozer length342 cmReference
6310 dozer length339 cmReference
Width152 cmReference
Height (hood)132 cmReference
Height (exhaust)193 cmReference
Gas Shipping weight3549 kgReference
Diesel Shipping weight3581 kgReference
Ground clearance33 cmReference
Gauge121 cmReference
Gauge172 cmReference
John Deere 350B attachments
bladeReference
350B Serial Numbers
Location:Serial number plate located on the front of the seat frame of the John Deere 350.Reference
1970117500Reference
1971121138Reference
1972138709Reference
1973164036Reference
1974191173Reference
1975219508Reference
FAQ: How to read a serial number table.Reference
John Deere 350B Tracks
Width30 cmReference
Length on ground175 cmReference
Area on ground1.1 m²Reference
Width35 cmReference
Area on ground1.3 m²Reference
Ground pressure0.3 barReference
Width83 cmReference
Area on ground2.9 m²Reference
Ground pressure0.1 barReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
