Tractor · 2005Unverified

John Deere 35C

Name: John Deere 35C
Brand: John Deere

John Deere 35C — Milenio C Series · 33 hp. Reference specifications; pending source verification.

The John Deere 35C is a compact tractor with a rating of 33 hp, placing it among the smaller models in its class. Manufactured from 2005 to 2015, the 35C features a 3-cylinder diesel liquid-cooled engine, which powers a four-wheel drive system through a 12-speed gearbox. The tractor's weight is listed as 1520 kg, and it is designed for use on areas of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

33 hp

Max power

33 hp

Weight

1520 kg

Catalogue coverage

Variants represented

Richest spec table

87 rows

Recorded power

33 hp

Recorded weight

1520 kg

Transmissions

12-speed synchronized

Production years

2005-2015

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

DistributorJohn DeereReference

ManufacturerGoldiniReference

Compact Utility tractorReference

Built in ItalyReference

Four-wheel driveReference

Power steeringReference

Hydraulic wet disc brakesReference

Two-post mid-mount folding ROPS.Reference

Engine

Lombardini 1.7L 3-cyl dieselReference

Fuel tank40.1 LReference

Engine (gross)24.6 kWReference

Lombardini LDW 1603Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.7 LReference

Bore/Stroke88 x 90 mmReference

Rated Power (gross)24.6 kWReference

Fuel systemindirect injectionReference

Air cleanerdryReference

Rated RPM2800Reference

Torque93.6 NmReference

Torque RPM2000Reference

StarterelectricReference

Starter volts12Reference

Oil capacity4.0 LReference

Coolant capacity6.0 LReference

Fuel TypedieselReference

No of Cylinders3 cylinderReference

Rated engine speed2,800 RPMReference

Engine torque at rated speed31.3 kgReference

Bore and stroke3.46x3.56 inchesReference

Cooling systemliquid-cooledReference

Transmission

12-speed synchronizedReference

TypesynchronizedReference

Gears12 forward and reverseReference

Clutchmechanical dry discReference

Oil capacity24.0 LReference

Transmission TypeSync ShuttleReference

forward and reverse optionsSynchro - 12 F and 12 RReference

Wheel Drive4WDReference

PTO & Hydraulics

Pressure150.0 barReference

Pump flow32.9 lpmReference

Rear TypeI/INReference

Rear lift (at ends)1399 kgReference

Rear lift (at 24"/610mm)1000 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Engine RPM540@2520Reference

Engine RPM1000@2620Reference

Dimensions

Wheelbase161 cmReference

Weight1520 kgReference

Front tire200/70R16Reference

Rear tire320/70R24Reference

Standard tires (ag)Front: 200/70R16. Rear: 320/70R24Reference

Length306 cmReference

Width110 cmReference

Height (ROPS)199 cmReference

Front tread84 to 120 cmReference

Rear tread89 to 126 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps45Reference

Battery volts12Reference

General

Make & ModelGoldiniReference

Rollover protective structureTwo-post mid-mount folding ROPS.Reference

Country of manufacturerItalyReference

Capacities

Capacity100.7 ciReference

Crankcase oil volume4.2 qtsReference

Power

Max Power33 hpReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM1,000 RPMReference

Engine Speed on Rear PTO speed1,000@2,620 RPMReference

Steering & brakes

BrakesHydraulic Wet DiscReference

Steering typePowerReference

Hydraulics

Maximum operating pressure2,176 psiReference

Rear Hitch category (SAE designation)Category I/INReference

Rear Hitch maximum lift capacity1,399.8 kgReference

Dimensions & weight

Height Over ROPS199.9 cmReference

Overall Length306.8 cmReference

Overall Width110.2 cmReference

Overall weight1,520 kgReference

Wheels & tyres

Rear Wheel Type320/70R24Reference

Rear wheel tread range35.1 to 49.9 inchesReference

Front Wheel Type200/70R16Reference

Front Wheel tread range33.4 to 47.5 inchesReference

Operator station

Cab AvailabilityAvailableReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
