Tractor · 2005Unverified
John Deere 35C
John Deere 35C — Milenio C Series · 33 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
33 hp
Weight
1520 kg
Hover a source tag to verify
Overview
DistributorJohn DeereReference
ManufacturerGoldiniReference
Compact Utility tractorReference
Built in ItalyReference
Four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post mid-mount folding ROPS.Reference
Engine
Lombardini 1.7L 3-cyl dieselReference
Fuel tank40.1 LReference
Engine (gross)24.6 kWReference
Lombardini LDW 1603Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.7 LReference
Bore/Stroke88 x 90 mmReference
Rated Power (gross)24.6 kWReference
Fuel systemindirect injectionReference
Air cleanerdryReference
Rated RPM2800Reference
Torque93.6 NmReference
Torque RPM2000Reference
StarterelectricReference
Starter volts12Reference
Oil capacity4.0 LReference
Coolant capacity6.0 LReference
Transmission
12-speed synchronizedReference
TypesynchronizedReference
Gears12 forward and reverseReference
Clutchmechanical dry discReference
Oil capacity24.0 LReference
PTO & Hydraulics
Pressure150.0 barReference
Pump flow32.9 lpmReference
Rear TypeI/INReference
Rear lift (at ends)1399 kgReference
Rear lift (at 24"/610mm)1000 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Engine RPM540@2520Reference
Engine RPM1000@2620Reference
Dimensions
Wheelbase161 cmReference
Weight1520 kgReference
Front tire200/70R16Reference
Rear tire320/70R24Reference
Standard tires (ag)Front: 200/70R16. Rear: 320/70R24Reference
Length306 cmReference
Width110 cmReference
Height (ROPS)199 cmReference
Front tread84 to 120 cmReference
Rear tread89 to 126 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps45Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
