Tractor · 1986Unverified

John Deere 3650

Name: John Deere 3650
Brand: John Deere

John Deere 3650 — Utility tractor · 105 hp. Reference specifications; pending source verification.

The John Deere 3650 is a tractor rated at 105 hp, positioning it within its class for power output. Manufactured from 1986 to 1993, this model is equipped with a 6-cylinder turbocharged diesel liquid-cooled engine, driving through a four-wheel drive system with a hydrostatic transmission. The listed weight of the 3650 is 6128 kg, and it is designed for use on plots ranging from 200 to 800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

105 hp

Weight

6128 kg

Catalogue coverage

Variants represented

Richest spec table

60 rows

Recorded power

105 hp

Recorded weight

6128 kg

Transmissions

16-speed

Production years

1986-1993

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Utility tractorReference

Built in Mannheim, Baden-Württemberg, GermanyReference

Four-wheel driveReference

Steeringhydrostatic powerReference

Wet disc brakesReference

Cab standard with optional air-conditioning.Reference

Engine

John Deere 5.9L 6-cyl dieselReference

Engine85.3 kWReference

John Deere 6359TL007Reference

turbocharged dieselReference

6-cylinderReference

liquid-cooledReference

Displacement5.9 LReference

Bore/Stroke107 x 110 mmReference

Power85.3 kWReference

Rated RPM2400Reference

Starter volts12Reference

Oil capacity12.5 LReference

Coolant capacity19.0 LReference

Transmission

16-speedReference

TransmissionPower SynchronReference

Gears16 forward and 8 reverseReference

Four gears in two ranges, plus reverse range, with two-speed low/high shift.Reference

PTO & Hydraulics

PTO (claimed)78.1 kWReference

Hydraulic system55.0 LReference

Typeclosed center constant pressureReference

Capacity55.0 LReference

Pressure186.0 barReference

Total flow44.0 lpmReference

Rear TypeIII/IIReference

Rear lift (at ends)5270 kgReference

Front HitchIIReference

Front lift (at ends)1630 kgReference

Front lift (at ends)2960 kgReference

Rear PTOindependentReference

Clutchhydraulic wet discReference

Rear PTO Type540/1000Reference

Engine RPM540@2178Reference

Engine RPM1000@2172Reference

Front PTOindependentReference

Front PTO Type1000Reference

Capacities

Fuel170.3 LReference

Dimensions

Wheelbase258 cmReference

Weight6128 kgReference

Front tire16.9x24Reference

Rear tire520/70x38Reference

Ag front16.9x24Reference

Ag rear520/70x38Reference

Length489 cmReference

Width226 cmReference

Height288 cmReference

Ground clearance34 cmReference

3650 Serial Number Location

Serial number plate on the left side of the tractor frame, above the front axle.Reference

Electrical

GroundnegativeReference

Charging amps55Reference

Batteries2Reference

Battery volts12Reference

Battery AH88Reference

Speeds

With 18.4-38 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
