Industrial Tractor · 1965Unverified
John Deere 400
John Deere 400 — Industrial tractor · 59 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
59 hp
Weight
4720 to 10500 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Industrial tractorReference
Built in Dubuque, Iowa, USAReference
Two-wheel driveReference
Final drivesplanetaryReference
SteeringmanualReference
SteeringpowerReference
Hydraulic wet disc brakesReference
Open operator station. Cab available.Reference
Variants
2020farm tractorReference
Engine
John Deere 3.3L 4-cyl dieselReference
John Deere 3.0L 4-cyl gasolineReference
Engine44.0 kWReference
John DeereReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke98 x 109 mmReference
Power44.0 kWReference
Air cleanerdryReference
Compression16.7:1Reference
Rated RPM2500Reference
Operating RPM1500-2500Reference
Torque196.6 NmReference
Torque RPM1300Reference
Starter volts12Reference
Oil capacity6.6 LReference
Coolant capacity11.4 LReference
gasolineReference
Displacement3.0 LReference
Bore/Stroke98 x 98 mmReference
Compression7.5:1Reference
Transmission
8-speed constant meshReference
8-speed power shuttleReference
Typeconstant meshReference
Gears8 forward and 4 reverseReference
Clutch279.4mm dry discReference
Oil capacity40.7 LReference
TransmissionDirection ReverserReference
Typepower shuttleReference
Clutchhydraulic wet discReference
Optional Direction Reverser allows for clutchless power shifts from forward to reverse in gears 1 to 4.Reference
Capacities
Fuel73.8 LReference
PTO & Hydraulics
Hydraulic system40.7 LReference
Typeclosed centerReference
Capacity40.7 LReference
Pressure155.1 barReference
Valves1 or 2Reference
Total flow24.6 lpmReference
Total flow49.2 lpmReference
Total flow106.0 lpmReference
Rear TypeIIReference
Rear PTOtransmissionReference
Rear PTOliveReference
Rear PTO Type540Reference
Rear PTO Type540/1000Reference
Mid PTOliveReference
Mid PTO Type1000Reference
Dimensions
Wheelbase208 cmReference
Weight4720 to 10500 poundsReference
Front tire7.50-16Reference
Rear tire13.6-28Reference
Weight1465 kgReference
Ag front6.00-16Reference
Ag rear12.4-28Reference
Industrial front7.50-16Reference
Industrial rear13.6-28Reference
Industrial rear16.9-24Reference
Industrial rear14.9-24Reference
Industrial rear14.9-28Reference
Length322 cmReference
Length330 cmReference
Width189 cmReference
Height (hood)138 cmReference
Height (exhaust)203 cmReference
Ground clearance33 cmReference
Clearance (front axle)45 cmReference
Front tread142 cmReference
Rear tread127 to 198 cmReference
Shipping2140 kgReference
Shipping2177 kgReference
Shipping3279 kgReference
Shipping4762 kgReference
John Deere 400 attachments
front-end loaderReference
backhoeReference
400 Serial Numbers
196514502Reference
196614680Reference
196742721Reference
196865176Reference
196982404Reference
1970102032Reference
1971117500Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Batteries1Reference
Batteries2Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
John Deere 94 Backhoe
Backhoe typeJohn Deere 94 BackhoeReference
John Deere 9505 Backhoe
Backhoe typeJohn Deere 9505 BackhoeReference
Digging depth414 cmReference
Loading height297 cmReference
Bucket force4399 kgReference
Speeds
With 16.9-24 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
