Snowmobile · 1972Unverified
John Deere 400
John Deere 400 — Model year 197219731974197519761977 · 28 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
28 hp
Weight
172 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
SnowmobileReference
Built in Horicon, Wisconsin, USAReference
Original price was $1,200 in 1972Reference
TrackedReference
Manual steeringReference
Mechanical band brakesReference
Suspensionbogie wheelReference
Engine
28HP Canadian Curtiss-Wright 339cc 2-cyl gasolineReference
Fuel tank20.8 LReference
Canadian Curtiss-Wright KEC 340Reference
gasolineReference
2-cylinderReference
air-cooledReference
Displacement20.7 ciReference
Bore/Stroke60 x 60 mmReference
Power20.9 kWReference
Fuel systemWalbro WR carburetorReference
Cooling systemfanReference
Rated RPM6500Reference
Startermanual-recoilReference
StarterelectricReference
Starter volts12Reference
SparkplugChampion L-78Reference
Sparkplug gap0.508 mmReference
Dimensions
Weight172 kgReference
Length261 cmReference
Width93 cmReference
Height106 cmReference
Track width39 cmReference
400 Serial Number Location
Serial number stamped on the rear right of the tunnel.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
