Industrial Tractor · 1960Unverified

John Deere 4010 Wheel

Name: John Deere 4010 Wheel
Brand: John Deere

John Deere 4010 Wheel — New Generation Series · 94 hp. Reference specifications; pending source verification.

The John Deere 4010 Wheel is a tractor designed for industrial use, boasting a rated power output of 94 hp, a typical power figure for its class. Manufactured from 1960 to 1963, this model features a 6-cylinder diesel liquid-cooled engine and two-wheel drive with an 8-speed gearbox. The tractor has an operating weight of 8378 to 8678 pounds. It is suited to operations on land with areas ranging from 200 to 800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

94 hp

Weight

8378 to 8678 pounds

Catalogue coverage

Variants represented

Richest spec table

85 rows

Recorded power

94 hp

Recorded weight

3800 kg

Transmissions

8-speed partially synchronized

Production years

1960-1963

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Industrial tractorReference

Built in Waterloo, Iowa, USAReference

Total built282 (total)Reference

Total built272 (diesel)Reference

Total built10 (gas)Reference

Two-wheel driveReference

Final drivesplanetaryReference

Steeringhydraulic powerReference

Differential hydraulic wet disc brakesReference

Open operator station.Reference

Variants

4010ag tractorReference

Dimensions

4010 Wheelindustrial tractorReference

Wheelbase244 cmReference

Weight8378 to 8678 poundsReference

Front tire9.00-16Reference

Rear tire18x26Reference

Industrial front9.00-16Reference

Industrial rear18x26Reference

Length379 cmReference

Width238 cmReference

Height225 cmReference

Height (hood)172 cmReference

Operating weight3800 kgReference

Operating weight3936 kgReference

Rear axle79 mmReference

Front tread162 cmReference

Rear tread177 cmReference

Engine

John Deere 4.9L 6-cyl gasolineReference

John Deere 6.2L 6-cyl dieselReference

Engine (net)70.2 kWReference

John DeereReference

gasolineReference

6-cylinderReference

liquid-cooledReference

Displacement4.9 LReference

Bore/Stroke102 x 102 mmReference

Power (net)68.7 kWReference

Compression7.5:1Reference

Rated RPM2200Reference

Torque309.2 NmReference

Torque RPM1500Reference

Starter volts12Reference

Oil capacity7.6 LReference

Coolant capacity22.7 LReference

dieselReference

Displacement6.2 LReference

Bore/Stroke105 x 121 mmReference

Power (net)70.2 kWReference

Air cleaneroil bathReference

Pre-heatingether injectionReference

Compression16.4:1Reference

Torque344.4 NmReference

Torque RPM1400Reference

Starter volts24Reference

Coolant capacity21.8 LReference

Transmission

8-speed partially synchronizedReference

TransmissionJohn Deere Syncro-RangeReference

Typepartially synchronizedReference

Gears8 forward and 3 reverseReference

Clutch304.8mm dry discReference

Oil capacity41.6 LReference

Synchro-Range requires the tractor to be stopped and clutch depressed to select one of four shift stations. Once a station is selected the tractor can be shifted on the move between the two forward gears (and single reverse in stations 1, 2, and 3) by using the clutch.Reference

Capacities

Fuel128.7 LReference

PTO & Hydraulics

Hydraulic system41.6 LReference

Typeclosed centerReference

Capacity41.6 LReference

Pressure137.9 barReference

Valves0 to 2Reference

Pump flow68.1 lpmReference

Rear TypeIIReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Front PTOindependentReference

Front PTO Type1000Reference

4010 Serial Numbers

19611000Reference

196220201Reference

196338200Reference

Final38200Reference

FAQ: How to read a serial number table.Reference

Electrical

Groundpositive (12V)Reference

Groundfloating (24V)Reference

Batteries2 (gas)Reference

Batteries4 (diesel)Reference

Battery volts6Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
