Industrial Tractor · 1972Unverified
John Deere 401A
John Deere 401A — Wheel Loader · 63 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
63 hp
Weight
7600 to 7700 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Wheel LoaderReference
Two-wheel driveReference
Final drivesinboard planetaryReference
Power steeringReference
Hydraulic wet disc brakesReference
Open operator station. ROPS available.Reference
Engine
John Deere 3.3L 4-cyl dieselReference
John Deere 3.0L 4-cyl gasolineReference
Engine (gross)47.0 kWReference
Engine (net)44.0 kWReference
Engine44.0 kWReference
John DeereReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke98 x 109 mmReference
Power (net)44.0 kWReference
Power (gross)47.0 kWReference
Air cleanerdryReference
Compression16.7:1Reference
Rated RPM2500Reference
Idle RPM800-2650Reference
Torque196.6 NmReference
Torque RPM1300Reference
Starter volts12Reference
Oil capacity5.7 LReference
Coolant capacity11.4 LReference
Intake valve clearance0.356 mmReference
Exhaust valve clearance0.457 mmReference
gasolineReference
Displacement3.0 LReference
Bore/Stroke98 x 98 mmReference
Power44.0 kWReference
Transmission
8-speed gearReference
8-speed power shuttleReference
TypegearReference
Gears8 forward and 4 reverseReference
Clutch279mm dry discReference
Typepower shuttleReference
Gears8 forward and reverseReference
Clutchhydraulic wet discReference
Capacities
Fuel73.8 LReference
PTO & Hydraulics
Hydraulic system49.2 LReference
Typeclosed centerReference
Capacity49.2 LReference
Pressure172.4 barReference
Pump flow106.0 lpmReference
Rear TypeIIReference
Rear PTOtransmissionReference
Rear PTOindependentReference
Rear PTO Type540Reference
Rear PTO Type540/1000Reference
Mid PTO Type1000Reference
Dimensions
Wheelbase201 cmReference
Weight7600 to 7700 poundsReference
Front tire7.50-16Reference
Rear tire16.9-24Reference
Weight1215 kgReference
Industrial front7.50-16Reference
Industrial rear16.9-24Reference
Length450 cmReference
Width203 cmReference
Height (hood)140 cmReference
Height (ROPS)221 cmReference
Gasoline Weight3447 kgReference
Diesel Weight3492 kgReference
Clearance (front axle)45 cmReference
Clearance (rear axle)33 cmReference
Front tread142 cmReference
Rear tread157 cmReference
John Deere 401A attachments
front-end loaderReference
backhoeReference
Attachment overview
Front-end loaderReference
BackhoeReference
John Deere 9250 Backhoe
Backhoe typeJohn Deere 9250 BackhoeReference
Transport height340 cmReference
Digging depth421 cmReference
2-Foot flat digging depth406 cmReference
Reach from pivot530 cmReference
Loading height342 cmReference
Swing Arc180°Reference
Bucket force3061 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
