Tractor · 2005Unverified
John Deere 40R
John Deere 40R — Milenio R Series · 28 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
28 hp
Weight
1139 kg
Hover a source tag to verify
Overview
DistributorJohn DeereReference
ManufacturerGoldiniReference
Orchard/Vineyard tractorReference
Built in ItalyReference
Four-wheel driveReference
Engine
Lombardini 1.6L 3-cyl dieselReference
Fuel tank22.0 LReference
Engine24.6 kWReference
LombardiniReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Bore/Stroke88 x 85 mmReference
Power24.6 kWReference
Air cleanerdryReference
Rated RPM3000Reference
StarterelectricReference
Starter volts12Reference
Transmission
6-speedReference
Gears6 forward and 3 reverseReference
Clutch215mm dry discReference
PTO & Hydraulics
PTO (claimed)20.9 kWReference
Rear TypeINReference
Rear lift (at ends)1000 kgReference
Rear PTO Type540/540EReference
Dimensions
Weight1139 kgReference
Length305 cmReference
Height (steering wheel)121 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
