Backhoe Loader · 1971Unverified
John Deere 410
John Deere 410 — Backhoe loader tractor · 66 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
66 hp
Weight
6445 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Backhoe loader tractorReference
Built in Dubuque, Iowa, USAReference
Two- or four-wheel driveReference
Final drivesinboard planetaryReference
Power steeringReference
Hydraulic wet disc brakesReference
Four-post ROPS. Cab optional with available heater.Reference
Engine
John Deere 3.6L 4-cyl dieselReference
Engine (gross)49.2 kWReference
Engine (net)46.2 kWReference
John DeereReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.6 LReference
Bore/Stroke102 x 110 mmReference
Power (net)46.2 kWReference
Power (gross)49.2 kWReference
Air cleanerdryReference
Rated RPM2500Reference
Torque217.0 NmReference
Torque RPM1300Reference
Starter volts12Reference
Oil capacity8.5 LReference
Coolant capacity12.3 LReference
Intake valve clearance0.356 mmReference
Exhaust valve clearance0.457 mmReference
Transmission
8-speed power shuttleReference
Typepower shuttleReference
Gears8 forward and reverseReference
Clutch254mm wet discReference
Oil capacity37.9 LReference
Capacities
Fuel73.8 LReference
PTO & Hydraulics
Hydraulic system77.6 LReference
Typeclosed centerReference
Capacity77.6 LReference
Pressure162.0 barReference
Pump flow143.8 lpmReference
Dimensions
Wheelbase208 cmReference
Weight6445 kgReference
Front tire11L-16Reference
Rear tire16.9-24Reference
Industrial front11L-16Reference
Industrial front7.50/8.00-16Reference
Industrial rear16.9-24Reference
Industrial rear18.4-24Reference
Industrial rear19.5L-24Reference
Industrial rear21L-24Reference
Length725 cmReference
Width213 cmReference
Height259 cmReference
Height (backhoe)353 cmReference
Operating weight6445 kgReference
Front tread154 cmReference
Rear tread167 cmReference
Backhoe & Loader
Dig depth467 cmReference
Dump angle127 cmReference
410 Serial Number Location
Serial number plate on the right side of the Deere 410 frame, above the front axle.Reference
Electrical
Charging systemalternatorReference
Batteries2Reference
Battery volts6Reference
Battery AH340Reference
Attachment overview
Front-end loaderReference
BackhoeReference
John Deere Backhoe
Backhoe typeJohn Deere BackhoeReference
Transport height353 cmReference
Digging depth467 cmReference
2-Foot flat digging depth462 cmReference
8-Foot flat digging depth431 cmReference
Reach from pivot568 cmReference
Swing Arc180°Reference
Bucket force4377 kgReference
Dipperstick force3246 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
