Backhoe Loader · 2001Unverified
John Deere 410G
John Deere 410G — Backhoe loader tractor · 96 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
96 hp
Weight
15000 to 18500 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Backhoe loader tractorReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD (optional)Reference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
ROPS canopy; cab with heat and A/C optionalReference
Engine
John Deere 4.5L 4-cyl dieselReference
Engine71.6 kWReference
John Deere 4045TReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.5 LReference
Bore/Stroke106 x 127 mmReference
Power71.6 kWReference
Rated RPM2100Reference
Torque378.3 NmReference
Torque RPM1400Reference
Starter volts12Reference
Oil capacity13.0 LReference
Coolant capacity16.1 LReference
Transmission
4-speed full powershiftReference
Typefull powershiftReference
Gears4 forward and 3 reverseReference
Oil capacity15.1 LReference
Capacities
Fuel136.3 LReference
PTO & Hydraulics
Hydraulic system98.4 LReference
Typepressure compensated load sensing (PCLS)Reference
Capacity98.4 LReference
Pressure249.9 barReference
Total flow162.8 lpmReference
Dimensions
Wheelbase210 cmReference
Weight15000 to 18500 poundsReference
Front tire11L-16Reference
Rear tire19.5L-24Reference
Industrial front11L-16Reference
Industrial rear19.5L-24Reference
Industrial front12.5/80-18Reference
Industrial front14.5/75-16.1Reference
Industrial rear21L-24Reference
Length728 cmReference
Width228 cmReference
Height (ROPS)281 cmReference
Height (cab)281 cmReference
Operating weight6804 kgReference
Operating weight8391 kgReference
Ground clearance35 cmReference
Backhoe & Loader
Dig depth190 to 240 inchesReference
Electrical
Charging systemalternatorReference
Charging amps90Reference
Batteries1Reference
Batteries2 (optional)Reference
Battery CCA950Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
John Deere Backhoe
Backhoe typeJohn Deere BackhoeReference
Digging depth482 cmReference
Digging depth (extended stick)609 cmReference
Reach from pivot599 cmReference
Reach from pivot (extended stick)721 cmReference
Loading height381 cmReference
Loading height (extended stick)472 cmReference
Bucket force6713 kgReference
Dipperstick force3964 kgReference
Speeds
With 19.5L-24 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
