Tractor · 1973Unverified
John Deere 4435
John Deere 4435 — Row-Crop tractor · 120 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
120 hp
Weight
5624 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Row-Crop tractorReference
Built in Monterrey, MexicoReference
The Mexican-built John Deere 4435 is similar to the US-built 4430.Reference
Two-wheel driveReference
Final drivesinboard planetaryReference
Open operator station.Reference
Engine
John Deere 6.6L 6-cyl dieselReference
Engine93.2 kWReference
John DeereReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.6 LReference
Bore/Stroke108 x 121 mmReference
Power93.2 kWReference
Rated RPM2200Reference
Firing order1-5-3-6-2-4Reference
Transmission
8-speedReference
TransmissionSynchro-rangeReference
Gears8 forward and 4 reverseReference
PTO & Hydraulics
PTO (claimed)89.5 kWReference
Rear TypeIIReference
Rear PTO Type540/1000Reference
Dimensions
Weight5624 kgReference
Links
:Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
