Industrial Tractor · 1965Unverified
John Deere 450 Loader
John Deere 450 Loader — Crawler Loader · 63 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
63 hp
Weight
7030 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Crawler LoaderReference
Built in Dubuque, Iowa, USAReference
DrivecrawlerReference
Open operator station.Reference
Variants
450crawlerReference
450CLcrawler-loaderReference
Engine
John Deere 3.3L 4-cyl dieselReference
Fuel tank117.3 LReference
Engine (gross)47.0 kWReference
Engine (net)42.5 kWReference
Drawbar (claimed)32.8 kWReference
John DeereReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke98 x 110 mmReference
Power (net)42.5 kWReference
Power (gross)47.0 kWReference
Air cleanerdryReference
Compression16.3:1Reference
Rated RPM2500Reference
Operating RPM1500-2500Reference
Torque196.6 NmReference
Torque RPM1300Reference
StarterelectricReference
Starter volts12Reference
Oil capacity8.5 LReference
Coolant capacity15.1 LReference
Transmission
8-speed gearReference
8-speed partial power shiftReference
TypegearReference
Gears8 forward and 4 reverseReference
Clutch304.8mm dry discReference
Two speeds forward, one reverse, in four ranges.Reference
Typepartial power shiftReference
Clutch279.4mm dry discReference
Oil capacity30.3 LReference
PTO & Hydraulics
Pump flow56.8 lpmReference
Pump flow87.1 lpmReference
Pump flow113.6 lpmReference
Rear PTOtransmissionReference
Rear PTOliveReference
Rear PTO Type1000Reference
Dimensions
Weight7030 kgReference
14-inch tracksReference
Weight1353 kgReference
Weight1589 kgReference
Length434 cmReference
Height (hood)144 cmReference
Height (exhaust)193 cmReference
Gasl 15630 diesel} Shipping weight7030 kgReference
Ground clearance36 cmReference
Gauge132 cmReference
John Deere 450 Loader attachments
bladeReference
front-end loaderReference
backhoeReference
450 Loader Serial Numbers
196510001Reference
196616160Reference
196742767Reference
196865000Reference
196982276Reference
1970102144Reference
Final117587Reference
FAQ: How to read a serial number table.Reference
Electrical
Charging systemalternatorReference
Batteries1Reference
Batteries2Reference
Battery volts12Reference
Battery AH90Reference
Attachment overview
BladeReference
Front-end loaderReference
BackhoeReference
In addition to the buckets, the 450 loader frame could be fitted with the 7710 bulldozer blade or the 7712 log loader with hydraulic grapple.Reference
John Deere 93A Backhoe
Backhoe typeJohn Deere 93A BackhoeReference
Transport height335 cmReference
Digging depth431 cmReference
2-Foot flat digging depth416 cmReference
Reach from pivot511 cmReference
Loading height292 cmReference
Bucket Rotation163°Reference
Swing Arc190°Reference
Bucket force4399 kgReference
John Deere 95A Backhoe
Backhoe typeJohn Deere 95A BackhoeReference
Transport height335 cmReference
Digging depth431 cmReference
2-Foot flat digging depth416 cmReference
Reach from pivot511 cmReference
Loading height292 cmReference
Swing Arc180°Reference
Bucket force4399 kgReference
John Deere 450 Loader Tracks
Width35 cmReference
Length on ground184 cmReference
Area on ground1.3 m²Reference
Ground pressure0.5 barReference
Width40 cmReference
Width45 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
