Industrial Tractor · 1964Unverified
John Deere 500
John Deere 500 — Industrial tractor · 80 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
80 hp
Weight
6805 to 7433 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Industrial tractorReference
Two-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Open operator station.Reference
Variants
3020farm tractorReference
Engine
John Deere 4.4L 4-cyl dieselReference
John Deere 3.7L 4-cyl gasolineReference
Engine59.7 kWReference
Diesel powershift Shipping3253 kgReference
Gas powershift Operating3308 kgReference
Diesel powershift Operating3371 kgReference
John DeereReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke108 x 121 mmReference
Power59.7 kWReference
Air cleanerdryReference
Compression16.5:1Reference
Rated RPM2500Reference
Torque256.3 NmReference
Torque RPM1400Reference
Starter volts24Reference
Oil capacity7.6 LReference
Coolant capacity18.0 LReference
gasolineReference
Displacement3.7 LReference
Bore/Stroke108 x 102 mmReference
Power57.9 kWReference
Compression7.6:1Reference
Torque252.2 NmReference
Torque RPM1800Reference
Starter volts12Reference
Transmission
8-speed full power shiftReference
8-speedReference
TransmissionPower ShiftReference
Typefull power shiftReference
Gears8 forward and 4 reverseReference
Oil capacity53.0 LReference
Full power shifts in forward and reverse ranges. Forward to reverse power shift in gears 1 to 4.Reference
TransmissionSynchro-RangeReference
Gears8 forward and 2 reverseReference
Oil capacity36.0 LReference
Capacities
Fuel94.6 LReference
PTO & Hydraulics
Hydraulic system36.0 LReference
Hydraulic system53.0 LReference
Capacity36.0 LReference
Capacity53.0 LReference
Pressure137.9 barReference
Valves1 or 2Reference
Total flow92.7 lpmReference
Rear TypeIIReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Front PTOoptionalReference
Front PTO Type1000Reference
Dimensions
Wheelbase208 cmReference
Weight6805 to 7433 poundsReference
Ag front7.50-16Reference
Ag rear16.9-28Reference
Length320 cmReference
Width243 cmReference
Height (hood)151 cmReference
Height (exhaust)208 cmReference
Ground clearance32 cmReference
Gas collarshift Shipping3086 kgReference
Gas collarshift Operating3204 kgReference
Diesel collarshift Operating3268 kgReference
John Deere 500 attachments
front-end loaderReference
500 Serial Number Location
Serial number plate on the rear of the tractor.Reference
Speeds
With 16.9-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
