Industrial Tractor · 1963Unverified
John Deere 5010I
John Deere 5010I — Industrial tractor · 129 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
129 hp
Weight
13550 to 13900 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Industrial tractorReference
Built in Waterloo, Iowa, USAReference
Total built2007Reference
The primary role of the John Deere 5010I was pulling a model 401 scraper.Reference
Two-wheel driveReference
Steeringhydraulic powerReference
Hydraulic wet disc brakesReference
Open operator station.Reference
Engine
John Deere 8.7L 6-cyl dieselReference
Engine (net)96.2 kWReference
John DeereReference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement8.7 LReference
Bore/Stroke121 x 127 mmReference
Power (net)96.2 kWReference
Air cleanerdryReference
Compression16:1Reference
Rated RPM2200Reference
Idle RPM600-2200Reference
Torque446.1 NmReference
Torque RPM1300Reference
StarterelectricReference
Starter volts24Reference
Oil capacity11.4 LReference
Coolant capacity37.9 LReference
Transmission
8-speed partially synchronizedReference
TransmissionJohn Deere Syncro-RangeReference
Typepartially synchronizedReference
Gears8 forward and 3 reverseReference
Clutchtwo 279.4mm dry discsReference
Oil capacity60.6 LReference
Capacities
Fuel185.5 LReference
PTO & Hydraulics
Hydraulic system60.6 LReference
Capacity60.6 LReference
Pressure137.9 barReference
Pump flow97.3 lpmReference
Rear PTOindependent (optional)Reference
Clutchhydraulic wet discReference
Rear PTO Type1000Reference
Dimensions
Wheelbase242 cmReference
Weight13550 to 13900 poundsReference
Front tire11.00-16Reference
Rear tire18.00-25Reference
Industrial front11.00-16Reference
Industrial rear18.00-25Reference
Length399 cmReference
Width192 cmReference
Height (hood)163 cmReference
Height (exhaust)275 cmReference
Shipping weight6146 kgReference
Operating weight6305 kgReference
Ground clearance33 cmReference
5010I Serial Numbers
19631000Reference
19644500Reference
19658000Reference
FAQ: How to read a serial number table.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
