Tractor · 2023Unverified

John Deere 5050E

Name: John Deere 5050E
Brand: John Deere

John Deere 5050E — 5E Series · 50 hp. Reference specifications; pending source verification.

The John Deere 5050E tractor has a rated power output of 50 hp, positioning it at the lower end of its class. Introduced in 2023, it features a 3-cylinder turbocharged diesel liquid-cooled engine and four-wheel drive, coupled with a 9-speed gearbox. The operating weight of the 5050E is specified as 5335 to 5809 pounds. It is suited for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

50 hp

Max power

50 hp

Weight

5335 to 5809 pounds

Catalogue coverage

Variants represented

Richest spec table

110 rows

Recorded power

50 hp

Transmissions

9-speed partially synchronized

Production years

2023-2023

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Utility tractorReference

Built in Pune, Maharashtra, IndiaReference

Original price was $25,141 in 2023 with 2WDReference

Two- or four-wheel driveReference

Final drivesplanetaryReference

Differential lockmechanical rearReference

Power steeringReference

Hydraulic wet disc brakesReference

Two-post folding ROPS.Reference

Engine

John Deere 2.9L 3-cyl dieselReference

Fuel tank71.9 LReference

Engine (gross)37.4 kWReference

John Deere 3029 EWRReference

turbocharged aftercooled dieselReference

3-cylinderReference

liquid-cooledReference

Displacement2.9 LReference

Bore/Stroke106 x 110 mmReference

EmissionsTier IVReference

Emission controldiesel exhaust catalyst and exhaust gas recirculationReference

Power (gross)37.4 kWReference

Rated RPM2100Reference

Torque208.8 NmReference

Torque RPM1500Reference

StarterelectricReference

Starter volts12Reference

Fuel TypeDieselReference

No of Cylinders3Reference

Emissions complianceFinal Tier 4Reference

Engine torque at rated speed209 NmReference

AspirationTurbochargedReference

Transmission

9-speed partially synchronizedReference

TransmissionSyncShuttleReference

Typepartially synchronizedReference

Gears9 forward and 3 reverseReference

Clutchdry discReference

Three synchronized gears in three ranges. Tractor must be stopped, and clutch used, to shift range.Reference

Transmission TypeSync ShuttleReference

forward and reverse options9F/3RReference

Wheel DriveMFWDReference

Rear Axle Drive TypePlanetaryReference

PTO & Hydraulics

PTO (claimed)27.6 kWReference

Typeopen centerReference

Rear valves1 or 2Reference

Mid valves3Reference

Pump flow48.4 lpmReference

SCV flow43.1 lpmReference

Total flow71.2 lpmReference

Steering flow22.7 lpmReference

Rear TypeII/IReference

Controltop link draft sensingReference

Rear lift (at ends)1799 kgReference

Rear lift (at 24"/610mm)1447 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2100Reference

Dimensions

Wheelbase204 cmReference

Weight5335 to 5809 poundsReference

Front tire11L-15Reference

2WD Rear tire14.9-28Reference

2WD Standard tires (ag)Front: 11L-15. Rear: 14.9-28Reference

4WD Standard tires (ag)Front: 9.5-24. Rear: 14.9-28Reference

Length363 cmReference

Flange rear axleReference

2WD Shipping2419 kgReference

4WD Shipping2634 kgReference

Max Drawbar1120 kgReference

Max Drawbar759 kgReference

John Deere 5050E attachments

front-end loaderReference

5050E Serial Numbers

Location:Serial number plate on the right side of the tractor frame, above the front axle.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps60Reference

Battery volts12Reference

Battery AH85Reference

Alternator size70 ampReference

Battery options12 VReference

Attachment overview

John Deere 512 loaderReference

John Deere 520M loaderReference

Speeds

With 16.9-28 rear tires.Reference

General

Make & ModelNJDXL02.9,339Reference

CreeperKit available for OOS SyncShuttle™ 9F/3R transmissionReference

SCV controlJoystick: MechanicalReference

Drawbar Maximum vertical load1,120.4 kgReference

Rear Axle TypeFlangeReference

DisplaySimple automotive-style instrument clusterReference

Country of manufacturerSub assembly in Pune, India, Final assembly in Augusta, GAReference

Working lightsHalogenReference

Type of headlight bulbHalogenReference

Type of beacon bulbKit: HalogenReference

Capacities

Capacity179 cu. in.Reference

Power

Max Power50 hpReference

Rated Power50 hpReference

Power boost0 percentReference

PTO

PTO Power37 hpReference

PTO torque rise22 percentReference

Rear PTO PowerAvailableReference

Rear PTO ControlMechanical (lever)Reference

Rear PTO RPM540 rpmReference

Engine Speed on Front PTO speed2,100 rpmReference

Hydraulics

Pump Rated Output (total)68.8 l/minReference

Remote Valves5Reference

Number of rear selective control valves (SCVs)TwoReference

Rear Hitch category (SAE designation)Category 2; convertible to 1Reference

Rear Hitch Sensing TypeTop linkReference

Dimensions & weight

Turning radius3.1 mReference

Overall weight2,419.9 kgReference

Wheels & tyres

Rear Wheel Type2WD: 14.9-28 R1 Bias\\nMFWD: 14.9-28 R1 BiasReference

Operator station

Cab Seat TypeMechanicalReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
