Tractor · 2008Unverified

John Deere 5055D

Name: John Deere 5055D
Brand: John Deere

John Deere 5055D — 5D Series · 55 hp. Reference specifications; pending source verification.

The John Deere 5055D is a compact tractor model with a rated output of 55 hp. It was produced from 2008 to 2014, featuring a 3-cylinder turbocharged diesel liquid-cooled engine. The tractor is equipped with four-wheel drive and a hydrostatic transmission, and its listed weight is 4189 to 4665 pounds. It is designed for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

55 hp

Max power

38.2 kW

Weight

4189 to 4665 pounds

Catalogue coverage

Variants represented

Richest spec table

114 rows

Recorded power

55 hp

Recorded weight

1900 kg

Transmissions

8-speed

Production years

2008-2014

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Utility tractorReference

Built in Pune, Maharashtra, IndiaReference

Original price was $18,754 in 2014Reference

Two-wheel driveReference

Final drivesplanetaryReference

Differential lockrear diff lock standardReference

Steeringhydrostatic powerReference

Mechanical wet disc brakesReference

Folding 2-post ROPSReference

Variants

5055D2WD EconomyReference

5055E4WD Mid-specReference

Engine

John Deere 2.9L 3-cyl dieselReference

Fuel tank60.6 LReference

Engine (gross)41.0 kWReference

John Deere PowerTech 3029Reference

turbocharged dieselReference

3-cylinderReference

liquid-cooledReference

Displacement2.9 LReference

Bore/Stroke106 x 110 mmReference

Rated Power (gross)41.0 kWReference

Air cleanertwo paper elementsReference

Rated RPM2300Reference

Starter volts12Reference

Max power38.2 kWReference

Power at rated engine speed35.3 kWReference

Fuel TypedieselReference

No of Cylinders3 cylinderReference

Rated engine speed2,300 RPMReference

Bore and stroke4.19x4.33 inchesReference

Cooling systemliquid-cooledReference

Transmission

8-speedReference

TransmissionSyncReverserReference

Gears8 forward and 4 reverseReference

Clutchdry discReference

Four gears in each of high (B), low (A), and reverse ranges. Synchronized shift between A and R ranges. Other shifts not synchronized.Reference

Transmission TypeSync ShuttleReference

forward and reverse optionsSyncReverser-8 F and 4RReference

Wheel Drive2WDReference

Rear Axle Drive TypeplanetaryReference

PTO & Hydraulics

PTO (claimed)35.0 kWReference

PTO (tested)38.2 kWReference

Typeopen centerReference

Pressure195.0 barReference

Rear valves1 or 2Reference

Mid valves2 (optional)Reference

Pump flow41.3 lpmReference

Total flow65.9 lpmReference

Steering flow24.6 lpmReference

Steering press.135.0 barReference

Rear Type2Reference

Controlposition and top-link draft controlReference

Rear lift (at 24"/610mm)1274 kgReference

Rear PTOindependentReference

ClutchmechanicalReference

Rear PTO Type540Reference

Power at rated PTO speed37.4 kWReference

Dimensions

Wheelbase195 cmReference

Weight4189 to 4665 poundsReference

Front tire7.5-16Reference

Rear tire14.9-28Reference

Ag front7.5-16Reference

Ag rear14.9-28Reference

Ag rear16.9-28Reference

Lawn/turf front27/12LL-15Reference

Lawn/turf rear21.5L-16.1Reference

Industrial front11L-15Reference

Industrial rear16.9-24Reference

Length340 cmReference

Width145 cmReference

Shipping weight1900 kgReference

Operating weight2116 kgReference

Clearance (front axle)47 cmReference

Front axleFlangeReference

John Deere 5055D attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps40Reference

Battery CCA623Reference

Battery volts12Reference

Total cold cranking amps623 ampsReference

Attachment overview

John Deere 512 loaderReference

John Deere 553 loaderReference

John Deere 5055D Height

Hood136 cmReference

ROPS240 cmReference

ROPS194 cmReference

Test results

Diesel 8-speed 2WDSeptember 24 - October 5, 2009Link: Nebraska Tractor Test 1954 fileReference

PTO performanceReference

Fuel use11.4 l/hourReference

Speeds

With 14.9-28 rear tires.Reference

General

Make & ModelJohn DeereReference

Front Axle TypeFlangeReference

Rollover protective structureFolding 2-post ROPSReference

Country of manufacturerIndiaReference

Capacities

Capacity179 ciReference

PTO

PTO Power47 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Steering & brakes

BrakesMechanical Wet DiscReference

Steering typeHydrostatic PowerReference

Hydraulics

Pump Rated Output (total)17.4 gpmReference

Hydraulics TypeOpen CenterReference

Maximum operating pressure2,828 psiReference

Remote Valves1 or 2Reference

Steering & Implements flow6.5 gpm (10.9 gpm)Reference

Rear Hitch category (SAE designation)Category 2Reference

Dimensions & weight

Height Over ROPS240.8 cmReference

Overall Length340.1 cmReference

Overall Width145.5 cmReference

Front axle clearance47.8 cmReference

Overall weight1,900.1 kgReference

Wheels & tyres

Rear Wheel TypeAg rear:14.9-28Reference

Front Wheel TypeAg front:7.5-16Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
