Tractor · 2008Unverified

John Deere 5065E

Name: John Deere 5065E
Brand: John Deere

John Deere 5065E — Model year 2008-20122013-20142015-2022 · 65 hp. Reference specifications; pending source verification.

The John Deere 5065E is a tractor model rated at 65 hp, placing it in the middle of its class for power. It was manufactured from 2008 to 2022. The 5065E is equipped with a 3-cylinder turbocharged diesel liquid-cooled engine, driving through a four-wheel drive system with a 9-speed gearbox, and has a listed weight of 4634 to 5500 pounds. This model is suitable for jobs covering approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

65 hp

Max power

43.2 kW

Weight

4634 to 5500 pounds

Catalogue coverage

Variants represented

Richest spec table

155 rows

Recorded power

65 hp

Transmissions

9-speed

Production years

2008-2022

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Utility tractorReference

Built in Pune, Maharashtra, IndiaReference

Two- or four-wheel driveReference

Final drivesplanetaryReference

Differential lockrear diff lock standardReference

Power steeringReference

Hydraulic wet disc brakesReference

Folding 2-post ROPS. Optional canopy. Optional deluxe canopy with lights and insulation.Reference

Engine

John Deere 2.9L 3-cyl dieselReference

Engine (gross)48.5 kWReference

John Deere PowerTech 3029HReference

turbocharged dieselReference

3-cylinderReference

liquid-cooledReference

Displacement2.9 LReference

Bore/Stroke106 x 110 mmReference

Rated Power (gross)48.5 kWReference

Air cleanertwo paper elementsReference

Pre-heatingcoolant heater (optional)Reference

Pre-heatingheavy-duty air pre-heater (optional)Reference

Rated RPM2400Reference

Idle RPM800-2600Reference

Operating RPM1800-2400Reference

Torque240.0 NmReference

Torque RPM1700Reference

Firing order1-2-3Reference

Starter volts12Reference

Coolant capacity9.5 LReference

Intake valve clearance0.356 mmReference

Exhaust valve clearance0.457 mmReference

Oil capacity8.5 LReference

Oil change100 hReference

Max power43.2 kWReference

Power at rated engine speed41.4 kWReference

Fuel TypedieselReference

No of Cylinders3 cylinderReference

Rated engine speed2,100 RPMReference

Engine torque at rated speed80.3 kgReference

Bore and stroke4.19x4.33 inchesReference

Compression ratio16.9:1Reference

Cooling systemliquid-cooledReference

Interval for engine oil change100 hrReference

Interval for engine coolant change10 qtsReference

Transmission

9-speedReference

9-speed partially synchronizedReference

TransmissionSyncReverserReference

Gears9 forward and 3 reverseReference

Clutchdry discReference

Oil capacity38.0 LReference

Oil typeJD Hy-GardReference

Three gears plus reverse in each of three ranges. Shuttle shift between 2 and R in all ranges. Other shifts are not synchronized. The SyncReverser is standard equipment on two-wheel drive models.Reference

TransmissionSyncShuttleReference

Typepartially synchronizedReference

Oil capacity39.0 LReference

Three gears (1-3) plus reverse (R) in each of three ranges (A-C). Shuttle shift between 2 and R in all ranges. Forward gear shifts in-range are synchronized. Shifts between ranges are not synchronized. The SyncShuttle is standard equipment on four-wheel drive models.Reference

Transmission TypeSync ShuttleReference

Wheel Drive4WDReference

Rear Axle Drive TypeplanetaryReference

PTO & Hydraulics

PTO (claimed)39.5 kWReference

PTO (tested)43.2 kWReference

2WD Hydraulic system37.9 LReference

4WD Hydraulic system39.0 LReference

Typeopen centerReference

2WD Capacity37.9 LReference

4WD Capacity39.0 LReference

Pressure195.0 barReference

Rear valves1 or 2Reference

Mid valves2 (optional)Reference

Pump flow43.1 lpmReference

Total flow68.9 lpmReference

Steering flow25.7 lpmReference

Steering press.135.0 barReference

Rear Type2Reference

Controlposition and top-link draft controlReference

Rear lift (at 24"/610mm)1447 kgReference

Rear PTOindependentReference

ClutchmechanicalReference

Rear PTO Type540Reference

Power at rated PTO speed42.1 kWReference

Capacities

Fuel68.1 LReference

Front axle4.5 LReference

Front hubs0.8 LReference

Capacity179 ciReference

Fuel tank81.8 LReference

Crankcase oil volume9 qtsReference

Dimensions

Wheelbase204 cmReference

Weight4634 to 5500 poundsReference

Front tire7.5-16Reference

Rear tire16.9-27 (2WD)Reference

Standard tires (ag)Front: 7.5-16. Rear: 16.9-27 (2WD)Reference

Standard tires (ag)Front: 9.5-24. Rear: 16.9-28 (4WD)Reference

Lawn/turf front27/12LL-15 (2WD)Reference

Lawn/turf front9.5-16 (4WD)Reference

Lawn/turf rear21.5L-16.1Reference

Industrial front11L-15 (2WD)Reference

Industrial front12.5-80-18 (4WD)Reference

Industrial rear16.9-24Reference

Length350 cmReference

Width145 cmReference

2WD Clearance (front axle)47 cmReference

4WD Clearance (front axle)34 cmReference

Front axle1640 mmReference

Flange axle rear axle1460 mmReference

2WD Shipping2101 kgReference

4WD Shipping2299 kgReference

4WD Operating2494 kgReference

John Deere 5065E attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps40Reference

Battery CCA623Reference

Battery volts12Reference

Total cold cranking amps925 ampsReference

Attachment overview

John Deere 512 loaderReference

John Deere 553 loaderReference

John Deere 5065E Height

Hood136 cmReference

ROPS245 cmReference

ROPS199 cmReference

Test results

Diesel 9-speed 4WDSeptember 20 - October 8, 2009Link: Nebraska Tractor Test 1956 fileReference

PTO performanceReference

Fuel use13.2 l/hourReference

Fuel use13.6 l/hourReference

Speeds

With 16.9-28 rear tires.Reference

General

Make & ModelJohn DeereReference

Rear Axle TypeFlangeReference

Rollover protective structureTwo-post folding ROPSReference

Country of manufacturerIndiaReference

PTO

PTO Power53 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Engine Speed on Rear PTO speed540@2,083 | 540E@1,588 RPMReference

Steering & brakes

Brakeshydraulic wet discReference

Steering typepowerReference

Hydraulics

Pump Rated Output (total)18.2 gpmReference

Hydraulics Typeopen centerReference

Maximum operating pressure2,828 psiReference

Remote Valves1 or 2Reference

Steering & Implements flow6.8 gpm (11.4 gpm)Reference

Rear Hitch category (SAE designation)Category IIReference

Rear Hitch maximum lift capacity1,799.9 kgReference

Rear Hitch Sensing Typeposition and top-link draft controlReference

Dimensions & weight

Height Over ROPS252.7 cmReference

Height Over Cab241.3 cmReference

Overall Length350 cmReference

Overall Width145.5 cmReference

Front axle clearance47.8 cmReference

Overall weight2,549.6 kgReference

Wheels & tyres

Rear Wheel Type16.9-28 agReference

Rear wheel tread range55.8 to 71.1 inchesReference

Front Wheel Type9.5-24 agReference

Front Wheel tread range57 to 76.7 inchesReference

Operator station

Cab AvailabilityAvailableReference

Cab Air conditioning, temperature differentialCab available with Heater and Air ConditioningReference

Seat SuspensionTRUEReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
